Assemble Heat Sink Device High Quality Green Tape For Led Lighting
- shenzhen
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
Soft And Compressibility Self Adhesive Thermal Insulation Tape For Cooling Components To The Chassis, Frame
-
Die-Cut Form High Quality Led Thermal Adhesive Tapes For Cooling Components To The Chassis, Frame
-
Electronic Components High Quality Manufacturer For Thermal Tape For Cooling Components To The Chassis, Frame
-
Can Replace The Hot Melt Adhesive And Screw High Quality Green Product Double Side Tape For Led Lights
-
Good Adhesion High Quality 50M Led Adhesive Thermal Transfer Tapes For Rdram Memory Moduies
-
Reduce Shock And Vibration Pro CPU Thermal Potting Smidahk
Product Details
| Material | Other, Fiberglass-net | Use | Masking | |
| Adhesive Side | Double Sided | Adhesive | Silicone | |
| Adhesive Type | Pressure Sensitive | Feature | Heat-Resistant | |
| Design Printing | No Printing | Place of Origin | Guangdong, China | |
| Brand Name | Sheen | Model Number | SA406FG |
Product Description
Assemble Heat Sink Device High Quality Green Tape For Led Lighting
| Product Information |
| Product Name | Assemble Heat Sink Device High Quality Green Tape For Led Lighting | |
| Item No. | SA406FG | Test Method |
| Color | White | Visual |
Carrier | Fiberglass | |
| Thickness (inch/MM) | 0.15 ±0.01 | ASTM D374 |
| Voltage Breakdown(V) | >2500 | ASTM D149 |
| Peel Adhesion | 1.8kg/25MM | PSTC-3 |
Shear Strengt 1.0 kg loading on 25 MM x 25 MM | >48 hrs | PSTC-7 |
Heat Resistance 0.5kg loading on 25MM x 25MM at 80°C | >24 hrs | |
| Thermal Conductivity (W/mk) | 1.0 | ASTM D5470 |
| Service Temperature | -30°C ~ 130°C | |
| Introduction | The SA406FG products are mostly used for bonding heat dissipation fins, microprocessors and other power consumption semiconductors. This type of adhesive tape possesses ultimate bonding strength with low thermal impedance, with which in effect can be able to replace the method of lubricating grease and mechanical fixing. the method of lubricating grease and mechanical fixing. | |
| Features and Benefits | 1.0 W/m-K Thermal Conductivity High bond strength to a variety of surfaces Double sided pressure sensitive adhesive tape High performance, thermally conductive acrylic Adhesive Withstand heat variation long term | |
| Typical Applications Include | -LED lighting -Cooling Components to the Chassis, Frame, or other type of heat spreader - Mass Storage Drives - Heat Pipe assemblies - RDRAM Memory Moduies - High Frequency Microprocessors - Notebook and Desktop PCs | |
| Product Display |
| Hot Sale |
| " href="http://sheen.en.china.cn/productgrouplist-801575840/thermally_conductive_pad.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801575840/thermally_conductive_pad.html" target="_blank">pad > | " href="http://sheen.en.china.cn/productgrouplist-801559511/Thermally_ConductiveTape.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801559511/Thermally_ConductiveTape.html" target="_blank"> tape > | " href="http://sheen.en.china.cn/productgrouplist-801533008/Thermal_silicone_RTV.html" target="_blank">Thermal silicone RTV > | " href="http://sheen.en.china.cn/productgrouplist-801584663/Thermal_Grease.html" target="_blank">Thermal grease > |
| " href="http://sheen.en.china.cn/productgrouplist-801646855/Phase_Change_Thermal_interface_Materials.html" target="_blank">Phase change thermal " href="http://sheen.en.china.cn/productgrouplist-801646855/Phase_Change_Thermal_interface_Materials.html" target="_blank"> interface materials > | " href="http://sheen.en.china.cn/productgrouplist-801559512/Thermally_Conductive_silicone_Pug.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801559512/Thermally_Conductive_silicone_Pug.html" target="_blank"> silicone pug > | " href="http://sheen.en.china.cn/productgrouplist-801646856/Thermally_conductive_insulators.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801646856/Thermally_conductive_insulators.html" target="_blank"> insulators > | " href="http://sheen.en.china.cn/productgrouplist-801586206/Thermally_conductive_graphite_sheets.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801586206/Thermally_conductive_graphite_sheets.html" target="_blank"> graphite sheets > |
| " href="http://sheen.en.china.cn/productgrouplist-801559513/Thermally_double_component_silicone_poly_urethane_.html" target="_blank">Thermally double " href="http://sheen.en.china.cn/productgrouplist-801559513/Thermally_double_component_silicone_poly_urethane_.html" target="_blank"> component silicone > | " href="http://sheen.en.china.cn/productgrouplist-801647661/Thermally_Conductive_plastics.html" target="_blank">Thermally conductive " href="http://sheen.en.china.cn/productgrouplist-801647661/Thermally_Conductive_plastics.html" target="_blank"> plastics > | " href="http://sheen.en.china.cn/productgrouplist-801533811/Epoxy_Adhesive.html" target="_blank">Epoxy adhesive > | " href="http://sheen.en.china.cn/productlist.html" target="_blank">More products > |
| Product Advantage |

|
|
|
|
Compared with traditional materials, the phase change thermal interface materials can cover and fill the gap and hollow between the contact interfaces when being liquid. |
| Company Overview |
| Certificate |
| Contact |
| We can make many specifications according to your request! For more information. Please contact us. | ||||||||||
|
| FAQ |
1. What are your main products? We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal grease. Samples of high quality green tape are available, but the freights need to be paid by the buyers. 2. What about the product quality and which certificate do you have? We have UL certificate and RoHS certificate. 3. How long does it take to deliver after order? For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as possible according to actual situation and customer's requirements. 4. What about your after-sale service? We fully guarantee our product quality and will provide free technical guidance on operations. |
