100% Warranty Weather Resistance 2 Parts Thermal Addition Silicone For Led Lights
| Product Information |
| Product Name |
100% Warranty Weather Resistance 2 Parts Thermal Addition Silicone For Led Lights |
||
| Item No. | TIV800-300A | Test Method | |
| Appearance & Color |
A | Brassy yellow |
Visual inspection
|
| B | Hoary |
||
|
Viscosity cps@25°C
|
A |
15000 | Brookfield DV-3 |
| B | 14500 | ||
| Density(g/ cm2) |
A | 1.9 | °C |
| B | 1.8 | ||
| Mixing rato |
A:B=1:1 | ||
| Operation time | 30MIN |
||
| Tack free time | 45-60 MINh |
||
| Curing time( 25°C) |
2H |
||
| Cured time( 25°C) |
24H |
||
| Cured time ( 60°C) |
20MIN |
||
|
Properities after cured
| |||
| Shear strengh | 12Mpa |
80*80mil 25°C |
|
| Thermal Conductivity,(W/m-K) | 30W/mk |
SL0731 |
|
| Shore hardness | 80D |
|
|
| Storage life | 12 months |
Room temperature,cool ventilated | |
| Introduction | The TIV800-300A Thermal Silicone RTV has high bond strength to coherer,ceramic,glass or plastic surfaces, and has good thermal conductivity. It can harder at ordinary temperature then the elastomer is electrically isolated and ageing resistive. |
||
| Features and Benefits |
-30 W/mk thermal conductivity -High bond strength to coherer,alloy,ceramic,glass or plastic surfaces -Withstand heat variation long term -Electrically isolating -ROHS compliant |
||
| Typical Applications Include |
-LED lighting -Cooling components to the Chassis, Frame or other type of heat spreader - Heat pipe assemblies - Motor control - Telecommunication hardware - Notebook and Desktop PCs |
||
| Product Display |
| Hot Sale |
|
Thermally conductive pad > |
Thermally conductive tape > |
Thermal silicone RTV > | Thermal grease > |
|
Phase change thermal interface materials > |
Thermally conductive silicone pug > |
Thermally conductive insulators > |
Thermally conductive graphite sheets > |
| " href="https://img13.fr-trading.com/productgrouplist-801559513/Thermally_double_component_silicone_poly_urethane_.html" target="_blank">Thermally double " href="https://img13.fr-trading.com/productgrouplist-801559513/Thermally_double_component_silicone_poly_urethane_.html" target="_blank"> component silicone > |
" href="https://img13.fr-trading.com/productgrouplist-801647661/Thermally_Conductive_plastics.html" target="_blank">Thermally conductive " href="https://img13.fr-trading.com/productgrouplist-801647661/Thermally_Conductive_plastics.html" target="_blank"> plastics > |
" href="https://img13.fr-trading.com/productgrouplist-801533811/Epoxy_Adhesive.html" target="_blank">Epoxy adhesive > | " href="https://img13.fr-trading.com/productlist.html" target="_blank">More products > |
| Product Advantage |
|
|
|
|
Compared with traditional materials, the phase change thermal interface materials can cover and fill the gap and hollow between the contact interfaces when being liquid. |
| Company Overview |
| Certificate |
| Contact |
|
We can make many specifications according to your request! For more information. Please contact us. | ||||||||||
|
| FAQ |
|
1. What are your main products? We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal grease. Samples of 2 parts thermal addition silicone are available, but the freights need to be paid by the buyers. 2. What about the product quality and which certificate do you have? We have UL certificate and RoHS certificate. 3. How long does it take to deliver after order? For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as possible according to actual situation and customer's requirements. 4. What about your after-sale service? We fully guarantee our product quality and will provide free technical guidance on operations. |
