18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood

18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood thumbnail-1
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood thumbnail-2
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood thumbnail-3
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood thumbnail-4
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood thumbnail-5
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood thumbnail-6
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood photo-1
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood photo-2
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood photo-3
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood photo-4
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood photo-5
18mm Film Faced Plywood Vietnam Shuttering Plywood 2 Times Pressed Film Faced Plywood photo-6
US$ 10 - 20 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
YELUWOOD, YELUWOOD
Model Number:
18mm shutting plywood
Contact Supplier Request Quote Chat Now
Ningjin County Yelu Wood Corporation Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name YELUWOOD, YELUWOOD
Model Number 18mm shutting plywood
Product Description



Names:

1. Shuttering Plywood/Film Faced Plywood / Marine Plywood
2. Brown phenolic resin film/WBP Glue.
3. 2440X1220X9MM, film faced plywood.

Description:
Film faced plywood is a concrete shuttering plywood, with a smooth, double-sided phenolic film overlay and sealed edges. It is also a multipurpose and maintenance free cladding panel for the transport industry and agriculture.

Specification:
Core: Poplar/birch/combi/hardwood core
Glue: WBP/Melamine/MR
Film Color: Dark brown, black film. Other colors, like yellow, green, grey, can be specially ordered.
Thickness : 4 6.5 9 12 15 18 21 24 27 30 mm
Size:

Width Length
1200      1200/ 1800/ 2400/ 2650/ 2700/ 3000/ 3660mm
1200     1220/ 1525/ 2440/ 3050/ 3660mm
1250     1250/ 2500mm
1500     1500/ 1800/ 2400/ 2700/ 3000/ 3600mm
1525 1525/ 2440/ 3050/ 3660mm
1875     1525/ 2440/ 3050/ 3660/ 3700mm



Application:
Smooth concrete form, cassette systems, transport equipment containers, trailer side boards, horse trailers, sliding doors.





Film Faced Plywood

Size

1220*2440MM/1250*2500MM/1500*3000MM or As per customer requested

Length(width) tolerance

+/-1mm

Thickness 9-30mm

Diagonal line

+/-2mm

Thickness tolerance +/-0.5mm

Film

Black/Brown Film



Logo

Logo-Comaccord, Customized logo by customers.



Surface

Smooth/wiremeshed(anti-slip)





Core material

Materials:Poplar/birch/combi/hardwood(eucalyptus)
Difference:
poplar-light weight, low density, low strength, cheap price;
hardwood-heavy weight, high density, high strength, high price;
(main film faced plywood in China is generally poplare core)

Glue

WBP(Weather/boil proof)/Melamine/MR
MR-boiled for one hour, reused times 6-8;
Melamine-boiled for 6-8 hours, reused times 8-12;
WBP-boiled for 48 hours, reused times 15-20;

Density

550-700kg/cbm
Poplar core: about 550kg/cbm
Hardwood core: about 570kg/cbm
Combi core: about 560kg/cbm
Birch core: about 700kg/cbm

Cycle life

6-20times

Moisture

6-12%

Warpage

<=1%

Edge

Sealed with water-proof paint, and different colors are available for us

Pallets

Pts/40'GP:16 pallets

Pts/40'HQ:18 pallets

Veneer layers (longitudinal grain with transverse grain crossed, glue-sprayed among each layers)

9mm:5 or 7 layers

12mm:7 or 9 layers

15mm:9 or 11 layers

18mm:11 or 13 layers

21mm:13 or 15 layers

25mm:15 or 18 layers

Hot press

Only two time hot preseed (Different: two times hot pressed plywood-smooth surface, one time hot pressed-low cost and cheap price), Comaccord only produce high quality product.

Capacity

500-1000m3/day



 18mm film faced plywood Vietnam shuttering plywood 2 times pressed film faced plywood18mm film faced plywood Vietnam shuttering plywood 2 times pressed film faced plywood18mm film faced plywood Vietnam shuttering plywood 2 times pressed film faced plywood18mm film faced plywood Vietnam shuttering plywood 2 times pressed film faced plywood18mm film faced plywood Vietnam shuttering plywood 2 times pressed film faced plywood
