48 Points Industrial Controller Mitsubishi PLC FX3G-24MR/ES Electrical Equipment

Consis Tech Equipment (Guangzhou) Co., Ltd.
48 Points Industrial Controller Mitsubishi PLC FX3G-24MR/ES Electrical Equipment thumbnail-1
48 Points Industrial Controller Mitsubishi PLC FX3G-24MR/ES Electrical Equipment photo-1
US$ 99 - 299 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
Mitsubishi
Model Number:
FX3G-24MR/ES
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Japan
Brand Name Mitsubishi
Model Number FX3G-24MR/ES

48 points Industrial Controller Mitsubishi PLC FX3G-24MR/ES Electrical Equipment,

with 100% original new quality from Japan.



1. Products guarantee:
1) 1 year guarantee;
2) Products itself has the quality problem can be exchanged within 15 days after receiving the goods.

If any needs, pls feel free to contact me freely.

2. Products range:

SpecificationsFX3G-14M_FX3G-24M_FX3G-40M_FX3G-60M_
I/O points256 total (combined local and CC-Link remote I/O)
Address rangeMax. 128 direct addressing and max. 128 remote I/O
Power supply100–240 V AC (+10 % / -15 %), 50/60 Hz
Program memory32,000 steps EEPROM (internal), exchangeable EEPROM memory cassette with loader function
Instruction Time0.21 µs or 0.42 µs / contact instruction
Integrated inputsNumber of inputs8142436
Input signal voltage24 V DC (±10 %)
Input formsink/source
Response timeApprox. 10 ms
IsolationPhotocoupler isolation
Integrated outputsNumber of outputs6101624
Switching voltage<240 V AC, <30 V DC (relay output), 5 – 30 V DC (transistor output)
Output type/formRelay or transistor
Max. loadresistive2A/point, max. 8 A total (relay), 0.5 A/point; max. 0.8 A for 4 output points/common terminal (transistor)
inductive80 VA (relay), 12 W/point (at 24 V DC); max. 19.2 W for 4 output points/common terminal (transistor)
Response time10 ms (relay), < 5 µs (for Y000 and Y001) / 0.2 ms (for all other outputs) (transistor)*
IsolationPhotocoupler isolation
High-speed counters21 total, with 16 1-phase (C235 - C250) and 5 2-phase (C251 - C255)
High-speed output counting range-2,147,483,648 to 2,147,483,647
24V DC service power supply400 mA
Environment0 – 55 °C ambient temperature; 5 – 95 % relative humidity

* The 40 and 60 I/O point transistor output base units have a 5µs response time for Y002





3.Our Business lines:

Mitsubishi

1. PLC :Q-PLC, FX1N, FX2N, FX1S, FX3G and FX3U series ;

2.Servo Driver and Motor MR-J2S, MRJ3, MR-J4,MR-JE;

3.Inverter FR-A740, FR-F740, FR-E740, FRD740 series;

4.HMI GT10, GT12, GT15, GT16 series.



Delta:

1.DVP-EH3,DVP-EH2,DVP-ES2/EX2,DVP-ES,DVP-SS2/SX2,DVP-EC2,DVP-EC3 series PLC;

2.AB,A2B2 series servo driver & servo motor

3.C2000,CP2000,CH2000,C200 series inverter

4. DOP B seriesHMIetc .



4. Company service:

Quality: 100% Original new with very low special price

Warranty :1year warranty service and 15exchange if product itself problem!

Promise: False one lost ten!!

Delivery: large in stock and can be very fast delivery



Any help, please feel free to contact us viaSkype: zqzj08
