Home > Products > Mitsubishi PLC > ORIGINAL QUALITY Mitsubishi PLC Q series CPU Module Q03UDECPU
ORIGINAL QUALITY Mitsubishi PLC Q series CPU Module Q03UDECPU
- 1000 Set / Sets per Month
- Shanghai/ Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Japan | Brand Name: | Mitsubishi | Model Number: | Q03UDECPU |
Product Description
ORIGINAL QUALITY Mitsubishi PLC Q series CPU Module Q03UDECPU
1.Performance Specifications
Specifications | Q03UDCPU, Q03UDECPU | Q04UDHCPU, Q04UDEHCPU | Q06UDHCPU, Q06UDEHCPU | Q10UDHCPU, Q10UDEHCPU | |
Type | Multi processor CPU module | ||||
I/O points | 3049/8192 | 4096/8192 | 4096/8192 | 4096/8192 | |
CPU self-diagnostic functions | CPU error detection,Watch Dog, battery error detection,memory error detection, programcheck, power supply error detection, fuse error detection | ||||
Battery buffer | All CPU modules are fitted with a lithium-battery with a life expectancy of 5 years. | ||||
Memory type | RAM, ROM, FLASH | RAM, ROM, FLASH | RAM, ROM, FLASH | RAM, ROM, FLASH | |
Memory capacity | overall | ≤32 MByte | ≤32 MByte | ≤32 MByte | ≤32 MByte |
max. for PLC program | 30 k steps (120 kByte) | 40 k steps (160 kByte) | 65 k steps (240 kByte) | 100 k steps (400 kByte) | |
Program cycle period | 20 ns/log. instruction | 9.5 ns/log. instruction | 9.5 ns/log. instruction | 9.5 ns/log. instruction | |
Dimensions (WxHxD) mm | 27.4x98x89.3 | 27.4x98x89.3 | 27.4x98x89.3 | 27.4x98x89.3 |
2.Our Business lines:
Mitsubishi
1. PLC :Q-PLC, FX1N, FX2N, FX1S, FX3G and FX3U series ;
2.Servo Driver and Motor MR-J2S, MRJ3, MR-J4,MR-JE;
3.Inverter FR-A740, FR-F740, FR-E740, FRD740 series;
4.HMI GT10, GT12, GT15, GT16 series.
Delta:
1.DVP-EH3, DVP-EH2,DVP-ES2/EX2,DVP-ES,DVP-SS2/SX2,DVP-EC2,DVP-EC3 series PLC;
2.AB,A2B2 series servo driver & servo motor
3.C2000,CP2000,CH2000,C200 series inverter
4. DOP B series HMI etc .
Quality: 100% Original new with very low special price
Warranty :1year warranty service and 15exchange if product itself problem!
Promise: False one lost ten!!
Delivery: large in stock and can be very fast delivery
Any more help, please feel free to contact us via skype:zqzj08
