Adjustable Coilover Suspension Kit for VW Jetta

Adjustable Coilover Suspension Kit for VW Jetta thumbnail-1
Adjustable Coilover Suspension Kit for VW Jetta photo-1
US$ 240 - 500 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Shock Absorber
Spring Type:
Coil Spring
Spring Material:
Steel
Contact Supplier Request Quote Chat Now
Tangshan Hengguang Mechanical Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin // Shanghai // Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Shock Absorber
Spring Type Coil Spring
Spring Material Steel
Shock Absorber Type Gas-Filled
Position Front
Car Make VW Jetta
OE NO. as your side OEM
Place of Origin Hebei, China
Brand Name TSHG
Model Number gh-005
Warranty 12 Months

Specifications

1.adjustable coilover suspension kit for VW Jetta
2.36 Levels of Dampening Adjustment
3.Custom-made Sample for Testing



 ♦adjustable coilover suspension kit for VW Jetta



adjustable coilover suspension kit for VW Jetta

♦Production Informantion:




Piston Rod
The piston rod, larger in diameter to increase the strength, is hard-chrome plated, induction hardening , and fine polished for greater resistance to corrosion, thus, assuring of smooth action.



Oil Seal
The special Multi-slip oil seal, made of oil and wear-resistant high quality synthetic rubber, having high sealing efficiency to keep vital oil and gas in and dirt out of the cylinder.



Rod Guide
The sintered iron rod guide with a PTFE-bushed sliding surface, assures smooth rod action with minimal resistance and wear.



Nitrogen Gas
Nitrogen gas is filled in the reservoir except hydraulic type shock absorbers.



Rebound Stopper
A rebound stopper, made of a high quality synthetic rubber, or resin, is installed on the piston rod to act as the rebound stop.



Pressure Tube
The pressure tube, with a precision sliding surface mirror-like finish is designed to withstand tremendous internal working pressures, thus, providing greater reliability.



Piston Valve
Unique automatic control rebound disc valve, which automatically adjusts to all ride conditions, is designed to assure maximum performance and smooth ride control.It also provides instant response for full performance without any time lag.



Absorber Oil
Our absorber oil with constant viscosity, blended with chemical additives provide optimum operating performance keeping its efficiency, in any weather conditions.



Bottom Valve
Compression disc valve, which provides excellent performance, has automatic control actions similar to the rebound piston disc valve.







Our Manufacturer FJ40 TOYOTA PARTS provides



---High performance quality



---Improved riding comfort under severe driving conditions, due to our unique rebound and compression control disc valve system which automatically adjusts to all ride conditions.



---Smooth operation and greater durability of the shock absorber.



---Improved road holding and necessary stability for safety.



---Better vehicle control, improved ride quality, and quieter operation by eliminating cavitation.



---No stone-shield protecting the working tube against flying stones because of no trouble on the working tube if the stones make dents on the outer tube.



---Assures a suitable damping force for active road-holding and excellent driving stability under any running condition.



---Reduces rolling and pitching of cars.



---Doubles effects of radial or wide tires when used in combination.


---Prevents nose dive at braking.



Spring Rates: 8kg Front and 10kg Rear

- 36 Levels of Adjustable Damper

- Pillow Ball Upper Mounts.

- Rubber Dust Covers.

- Adjustable Ride Height

- Aggressive Spring Rates

- Single-Cylinder Design





♦Our products:

1. Car suspension springs;

2. Car lowering springs

3. High tension springs

4. Shock absorbers

♦Our Services:

1. Reply your enquiry in 24 working hours;



2. Experienced staffs will answer all your questions in professional and fluent English;



3. Customized design is available; OEM & ODM are welcome;



4. Exclusive & unique solution can be provided by our well-trained and professional engineers;



5. Special discount can be offered with large quantity;



6. We will try our best to meet your requirements and supply you best quality auto coil springs for susp-ension system.

♦Our advantage:

1. We are manufacturer, not trade company;

2. 10 years experience guarantees the good quality;

3. Very competitive price;

4. Can supply more than 500 models different car spring and can do OEM.

5. Perfect after-sales service. We have 1 year commercial guarantee.

♦Product show:

adjustable coilover suspension kit for VW Jetta

adjustable coilover suspension kit for VW Jetta



adjustable coilover suspension kit for VW Jetta





♦Our Factory & Workshop:

adjustable coilover suspension kit for VW Jetta





♦Produce Process:

♦Packaging:



♦Our Certificate: ISO9001

adjustable coilover suspension kit for VW Jetta

♦We supply the springs and shock absorbers for the following brands:





♦How to order:

1. Please send us your technical drawing with detailed specification or provide us with samples.



2.Confirm all  the terms, such as delivery time, payment terms, package, shipment terms, etc.



3.Send clients samples for testing.



4.Start mass production after samples approved



5. Notification of shipping time



6. Client feedback and After-sales Service.



♥ If any questions, pls fell free to contact our sales. We will reply your email in 24 hours. Thank you!
