Prouduct show
1. Product Pictures of glass sliding door portable temperature control display refrigerator freezer
2.Description of glass sliding door portable temperature control display refrigerator freezer
sliding door ice cream freezer
1.Powder Coated Cold Steel Roll
2.Embossed Aluminum Sheet
3.two curved slidding lids
4. CE
| curved glass door chest freezer | ||||
| Model | XS-160YX | XS-260YX | SD260 | SD320 |
| Curved Sliding Lids Chest Showcase | Curved Sliding Lids Chest Showcase | Curved Sliding Lids Chest Showcase | Curved Sliding Lids Chest Showcase | |
| Capacity | ||||
| Gross Volume | 160L | 260L | 260L | 320L |
| Net Volume | 110L | 190L | 208L | 248L |
| Dimension | ||||
| Product (W*D*H) | 665*705*875mm | 990*705*875mm | 1108*596*806mm | 1108*596*850mm |
| Packing (W*D*H) | 735*760*950mm | 1060*760*950mm | 1168*656*870mm | 1168*656*895mm |
| Function | ||||
| Thermostat | Mechnical | Mechnical | Mechnical | Mechnical |
| Indicator | Red Compressor On Indicator | Red Compressor On Indicator | Red Compressor On Indicator | Red Compressor On Indicator |
| Wheels | 4 Universal, diameter 33mm | 4 Universal, diameter 33mm | 4 Universal, diameter 33mm | 4 Universal, diameter 33mm |
| Scraper | 1 / ABS | 1 / ABS | 1 / ABS | 1 / ABS |
| Drain Pipe | Yes | Yes | Yes | Yes |
| Lock | Optional | Optional | Optional | Optional |
| Thermometer | Optional | Optional | Optional | Optional |
| Basket | 1 | 1 | 1 | 1 |
| Performance | ||||
| Test Condition | 38oC, 40-70%RH | 38oC, 40-70%RH | 38oC, 40-70%RH | 38oC, 40-70%RH |
| Test Results | <-18oC Warmest | <-18oC Warmest | <-18oC Warmest | <-18oC Warmest |
| Climate | ST | ST | ST | ST |
| Ambient Temperature Range | -18oC~38oC | -18oC~38oC | -18oC~38oC | -18oC~38oC |
| Insulation Resistance | >50 Mohm | >50 Mohm | >50 Mohm | >50 Mohm |
| Grounding Rsistance | <0.1 Ohm | <0.1 Ohm | <0.1 Ohm | <0.1 Ohm |
| Cabinet | ||||
| Isolation layer / Blow Agent | Polyurethane / R141B | Polyurethane /R141B | Polyurethane / R141B | Polyurethane / R141B |
| Isolation Thicknes | 60mm | 60mm | 60mm | 60mm |
| Cabinet Shell | Powder Coated Cold Steel Roll | Powder Coated Cold Steel Roll | Powder Coated Cold Steel Roll | Powder Coated Cold Steel Roll |
| Cabinet Liner | Embossed Aluminum Sheet | Embossed Aluminum Sheet | Embossed Aluminum Sheet | Embossed Aluminum Sheet |
| Lid | ||||
| Type | Two Curved Sliding Lids | Two Curved Sliding Lids | Two Curved Sliding Lids | Two Curved Sliding Lids |
| Lid Frame | ABS+PVC, grey color | ABS+PVC, grey color | ABS+PVC, grey color | ABS+PVC, grey color |
| Lid Handle | Strip | Strip | Strip | Strip |
| Lid Glass | Single Layer Toughened Heat Reflecting Glass | Single Layer Toughened Heat Reflecting Glass | Single Layer Toughened Heat Reflecting Glass | Single Layer Toughened Heat Reflecting Glass |
| System | ||||
| Compressor | ||||
| Supplier | Baixue/Huayi | Baixue/Huayi | Baixue/Huayi | Baixue/Huayi |
| Refrigerant | R12/R134a | R12/R134a | R12/R134a | R12/R134a |
| Fan Motor | ||||
| Input Power | 25W | 25W | 25W | 25W |
| Supplier | Local | Local | Local | Local |
| Evaporator | Steel Tube Coil | Steel Tube Coil | Steel Tube Coil | Steel Tube Coil |
| Material | Steel Tube | Steel Tube | Steel Tube | Steel Tube |
| Condenser | Pre Fan Cooling + Hot Wall | Pre Fan Cooling + Hot Wall | Pre Fan Cooling + Hot Wall | Pre Fan Cooling + Hot Wall |
| Material | Steel Tube | Steel Tube | Steel Tube | Steel Tube |
| Power Cord | Per Destination | Per Destination | Per Destination | Per Destination |
| Stuffing Quantity(40'HQ) | 198 | 231 | 108 | 108 |
3.More similar models for your choose
4.The detail pics of mass production & packaging of glass sliding door portable temperature control display refrigerator freezer
