Specifications
DASION concrete mixer truck hydraulic pump1. Mixing capacity: 3m3;
2. Truck chassis: Dongfeng Motor (China)
China famous DSTM-3 concrete mixer truck hydraulic pump
Technical features of DSTM-3
DSTM-3 Concrete Mixer Truck:
1. Mixing capacity: 3m3;
2. Truck chassis: Dongfeng Motor (China);
3. Mixing tank: Adopt American EATON Hydraulic system & Germany ZF Reducer;
4. Description to mixing part: Adopts roasted progress with abreacting shape, steady and reliable slew, quick discharging, low residue rate, convenient operation, long service life.
Main configuration and parameters of DSTM-3 Concrete Mixer Truck
Mixing tank body:
Mixing capacity----------------------------------------------------------------3m3
Tank volume--------------------------------------------------------------------7.35m3
Tank lean angle----------------------------------------------------------------15°
Concrete charging speed------------------------------------------------------≥3m3/min
Concrete discharging speed---------------------------------------------------≥2m3/min
Discharging residual ratio-----------------------------------------------------≤0.5%
Tank rolling speed--------------------------------------------------------------0-14r/min
Hydraulic oil pump------------------------------------------------------------America Eaton
Hydraulic motor----------------------------------------------------------------America Eaton
Reducer--------------------------------------------------------------------------Germany ZF
Water feeding system:
Water tank-----------------------------------------------------------------------450L
Feeding type--------------------------------------------------------------------Air pressure, Pneumatic
Truck chassis:
Chassis brand-------------------------------------------------------------------Dongfeng Motor
Engine model & Power rated-------------------------------------------------ISDe210 30 & 210HP
Emission standard--------------------------------------------------------------EURO-III, 6.5L
Wheel base----------------------------------------------------------------------3800mm
Approach/Departure angle----------------------------------------------------20°/13°
Outline dimension--------------------------------------------------------------7450x2500x3600mm
(Parameter is changed without prior notice.)
More Info. About This Concrete Mixer:
/product/dstm3concretemixertruck.html
Attentions:
If you are interested in our products, please do not hesitate to contact us on TradeManager client.
Or, you can click here to send us an inquiry.
Your inquiry will be given prompt attentions and reply within 12 hours.
