RGZ series hot juice filling machine 4-in-1,tea filling machine:
Usage:
This series machine integrates washing,granular filling,filling and capping into one unit.It can be used for hot filling production of different kinds of fruit juice,tea.This series machine can also be used for filling purified and mineral water.
Features:
1.The suspending bottleneck clamping design make the bottle stable during the high speed moving conditions.By changing a few parts,it can meet the need of production of different types of bottles easily.
2.The new generation of stainless steel grab is adopted and the grabs have no contact with the area above the bottle's screw thread.Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
3.The advanced micro negative-pressure filling technology used in this machine makes the filling quick,steady and accurate.The beverage -holding tank is fully-closed and also,temperature control device and CIP washing interface are intalled.
4.This machine can meet all the technical requirements for hot filling below 95 degree.And before capping,bottle mouth will be cleaned by RO washing device.
5.Advanced technologies ,such as human-machine interface touch-screen and PLC computer program control are adopted in this machine
| Technical Data | ||||
| Model | RGZ14/12/12/5 | RCGFR18/18/18/6 | RCGFR24/24/24/8 | RCGFR32/32/32/8 |
| The number of Washing, Filling, Capping | 14-14-12-5 | 18-18-18-6 | 24-24-24-8 | 32-32-32-8 |
| Producing capacity: The number of bottle(500ml)/hour |
3000-4000 | 5000-7000 | 8000-12000 | 12000-15000 |
| Applicable bottle specifications (mm) | H=170-320 | Φ=50-100 (330∼1500ml) |
||
| Pressure ( MPa) | 0.25-0.3 | |||
| General power (kw) | 1.5+0.37 | 2.2+0.37 | 3+0.45+0.25 | 4+0.45+0.25 |
| Overall dimension (mm) (L×W×H) | 2300×1680×2650 | 2500×1760×2650 | 3100×2100×2650 | 3800×2800×2650 |
| Weight(kg) | 2600 | 3500 | 4800 | 6500 |
