Carbonated soft Drink Mixer
- 15 Set / Sets per Month
- Shanghai port
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | BEIERDE | Model Number | QHS-5000 | |
| Processing Types | Carbonated Beverage | Voltage | 380V/220V | |
| Certification | CE&ISO9001 | Warranty | One Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Capacity:5000kg/hAutomatic, convenient
Easy in maintenance
304 stainless steel
QHS-5000 drink Mixer
Features:
1. QHS series drink mixer is designed and made for improving the proportion of water, syrup and carbon dioxide.
2. It adopts foreign advanced technology static mixer to lighten water layer, extend carbonizing to assure mixing result and deoxying.
3. It adopts high-quality water pump and SIEMENS electrical equipment and other parts to form complete automatic control system.
4. The advantages are motor coordinating, beautiful appearance, convenient rinsing, high automatic level.
5. It is suitable for mixing all kinds of drink, such as soda water, fruit juice, cola and drinks.
6. Drink mixer machine is used for mixing water – syrup CO2 in beverage industry.
7. It can mix syrup and drink water and CO2 at the same time. It can also be used in diluting beer and aerate beer.
Main Technological Specification:
| Production capacity (kg/h) | 5000 | |
Water-sugar mixing proportion | 3:1-10:1 | |
Volume of CO2&H2O | >2.6 | |
Intel temperature of the chilled water(°C) | 3-5 | |
Working pressure of precarbonation vessel and svrup vessel(Mpa) | 0.05-0.08 | |
Working pressure of storing vessel(Mpa) | 0.2-0.5 | |
