Help CenterFH-5001 Spiral Hydraulic Hose
Related Products
-
Square PVC Hose With Platic Wire Good Quality PVC PipeUS$ 0.2 - 4.6MOQ: 700 Meters -
2.1/2 PVC Pipe Insulated PVC Pipe 5'' 6'' DiameterUS$ 0.2 - 4.6MOQ: 700 Meters
-
FH-5008Y 4 Inch Plastic PipeUS$ 0.56 - 3.89MOQ: 300 Meters
-
Transparent Pvc Clear HoseUS$ 0.1 - 0.2MOQ: 1000 Meters
-
High Quality Plastic Flexible Corrugated HoseUS$ 0.3 - 0.8MOQ: 300 Meters
Spiral hose for sale
Product details
1. Made of: new PVC materials High quality
2. Specification: 3/4" to 10" 19mm-250mm
3. Length: 20m/roll,30m/roll
4. Color:green,yellow,red,black,clear etc
5. diameter thickness as per the customers'requirement
6.Good flexibility. No poison and no smell.
7.Reinforced rigid plastic wire screw inserted into the inner wall of flexible PVC hose.
8.To be light in weight with good resistance to the hard weather conditions and minus pressure, and small bending radius.
9.Excellent resistance to pressure, external impacts, chemical, gases, light acids and saline water.
10.Working Temperature: -5 centigrade degree to +65 centigrade degree.
11.Ideal subsititute for rubber hose, cement hose and metal hose in many areas.
12.Widely used for pumping and delivery fluids such as water ,oil and powder in agriculture, factory and construction , can fit to PVC pipe by PVC glue.
13.Especally ideal for ventilation and air conditioning system,industrial vacuum cleaner,and granulate conveying systems.
As suction and transport hose suitable for below substance.
Gaseous medias such as vapors and smoke.
Liquid medias.
Small granultes such as dusts,powders and ect.
agriculture, fishing and construction.
13.Technique parameter:
Size(in) |
Inner Diameter (mm) |
Thickness (mm) Skin*tendon |
Working pressure (bar) |
Bursting pressure (bar) |
Weight Kg/roll |
Packing size height*diameter(cm) |
Length (m) |
3/4 |
19 |
1.1*2.2 |
8 |
32 |
9 |
16*45 |
30 |
1 |
25 |
1.3*2.6 |
8 |
32 |
12 |
20*50 |
|
1-1/4 |
32 |
1.6*3 |
8 |
30 |
16 |
22*68 |
|
1-1/2 |
38 |
2.1*4 |
8 |
26 |
20 |
26*75 |
|
2 |
51 |
2.6*5 |
7 |
24 |
27.5 |
32*85 |
|
2-1/2 |
64 |
2.8*5.5 |
6 |
20 |
36 |
32*110 |
|
3 |
76 |
3.1*6 |
5 |
20 |
45 |
35*115 |
|
4 |
102 |
3.6*7 |
5 |
16 |
68 |
48*145 |
|
5 |
127 |
4.1*8 |
4 |
13 |
93 |
40*180 |
|
6 |
152 |
4.6*9 |
4 |
12 |
135 |
48*180 |
