Specifications
1.cable tv hdmi converter2.support 4Kx2K /1080p/1080i/720p
3.OFC conductor
4.triple shielding
5,FCC,UL,CE,ROHS
cable tv hdmi converter
Specifications
1.cable tv hdmi converter
2.support 4Kx2K /1080p/1080i/720p
3.OFC conductor
4.triple shielding
5,FCC,UL,CE,ROHS
Product Name:
HDMI A to HDMI A cable tv hdmi converter
Connector:
HDMI Plug 19P to HDMI Plug 19P Golded plated or Ni-plated(optional)
Description:
1.) V 1.4 HDMI A to A , 30AWG,with colouful Nylon braiding, OD 7.2mm
2.) 24K gold plated connector, 99.99% Oxygen free copper conductor
3.) 4K x 2K resolution (4 times higher resolutions as 1080p);
4.) Supports more colour spaces as DSC and SYCC601,Deep colour,X.V. colour
5.) Support ARC and HEAC
6.) ABS shell, Gun gray
7.) 32/30/28/26 AWG.
8.) L=1M,1.5M, 3M, 5M---40M (optional)
Features:
1) 24K gold-plated connectors ensure superior signal transfer and lifetime of maximum performance;
2) 4 screened twisted pairs of OFC stranded conductors with foam PE insulation layer, improve the high frequency response for wide-bandwidth and efficient signal transfer;
3) AL foil wrapped around each twisted pair. AL foil wrapped around the whole inner cores and tinned copper braid shielding,treble screened to provide complete immunity to environmental EMI and RFI.
4) These High speed cables are constructed to the highest quality with full triple layer shielding from end to end, strong, solid wire welds and the highest quality materials including high purity copper, gold plated connectors and tin plated conduits.
Electrical Features:
1)100% Open & Short Tests;
2) Hi-pot: DC 300v 10ms
3) Insulation Resistance: 10m ohm min
4) Contact Resistance: 3max;
5) RoHS approval and support 1080P.
Blister Packing:
1)Triple/Double Layers Blister Packing;
2)OEM design logo available;
3)20 or 25pcs to an Export Carton;
4)Cable Length within 15ft (5 meter
Picture B: Ethernet Channel
Picture C: Audio Return Channel
Picture D: 4K × 2K Resolution Support
