Specifications
1.Image intensifier for digital radiology is effective entrance field of view size: 215mm.2.by air.
X-ray Image Intensifier
I. Brief Introduction:
It is the electronic output equipment which converts the x-ray image into the visible light image. It is installed on the x-ray TV system, which is applicable to the x-ray fluoroscopy and radiograph.
II. Construction:
It is composed of x-ray image multiplier tube, tube container, high voltage power supply (which is set inside of tube container) and low voltage power supply (which drives the high voltage power supply).
III. Application:
The nominal entrance field of view is 23cm (9inch), which is mainly application to C-arm, diagnosis radiograph and fluoroscopy x-ray machine, digital RF x-ray machine, lithotrity and industrial detection X-ray machines etc.
IV. Main Technological Parameters:
1. Photoelectric Performance:
(1) Input screen size: 230mm
(2) Effective entrance field of view size: 215mm
(3) Output image diameter: 20mm
(4) Limiting resolution: 52Lp/cm
2. Low Voltage Power Supply Performance Parameters:
(1) Input voltage: 86V~ 265V
(2) Input power supply frequency: 50Hz/60Hz
(3) Output voltage: 24V±0.5V
(4) Output current (effective value): 1.5A
3. Standard Configuration:
(1) 24V power supply box: 1 piece
(2) 24V power supply cable: 2 pieces
(3) Ground wire: 1 piece
(4) Image intensifier: 1 piece
(5) Service manual: 1 copy
(6) Quality Certificate: 1 copy
Our company founded in 1999, Weifang Newheek Medical Equipment Co., Ltd is one of the high technology medical X-ray equipment manufactures in the world. It is special engaged in the research, development, production and sale of medical image equipments.Our company mainly produces image intensifier, image intensifier television system, X-ray fluoroscopy, photography machine and other accessories. The whole enterprise makes full implementation of international GB/T19001-2008/ISO9001:2008 and ISO 13485:2003 quality management system to ensure the product quality and sets the international sales service network. 2012 we founded our branch Weifang Newheek Electronic Technology Co.,Ltd. High technology with fine quality, good reputation with satisfied service introduce Newheek developing into a dazzling star in the medical equipment industry.
certificate
packing size:53.5*47*50cm
Packaging materials:carton
We are shipping this product by air .
