Help CenterOven Thermostat With Ajustable and Limit Temperature Function.
Related Products
Specifications
Oven Thermostat:1. Electrical performance:16A-250V/AC
2. Temperature range:-35~+320 degree celsius
3. Life: >100,000 times
Oven Thermostat:
Thermostat specification:
1. Electrical performance: 16A-250V/AC
2. Temperature range: 50°C~+320°C(thermosistor)
50°C~320°C(temperature Limiter, manual reset)
3 Diff: according to the customer requirement.
4. Life: >100,000 times(Thermosistor)
>6000 times (Temperature lmiter, manual reset)
5. Side of boay: 150°C
Principle of performance and Application:
When the temperature of the controlled object is changed,the inner working substance of
thermostat sensible bulb produce a corresponding thermal expansion and contraction physical
phenomenon (the working substance volume change), at which connected withthe diaphragm of
sensible bulb produces expansion or contraction.Through the leverage to drive switch on/off action,
the purpose is to achieve constant temperature. WYH series thermostats have temperature control
accurate, reliable, small differential, temperature adjustment range, and large overload
currentper formance characteristics.
Usage:
To be applied to kitchen freezer,chiller, refrigerator, ice machine, fishpond for temperature control
use.
