Hot sales 8fun 36v 350w electric bike motor kit with 36v 15ah samsung downtube battery for 36v 350w central electric bike motor
SHENZHNE LITHPOWER provides a vertical supply chain from lithium ion single cells, battery packs to Battery modules with matched BMS as well Chargers as a completely turn-key power solution.We provides a vertical supply chain from single cells, battery packs to Battery modules with matched BMS as well Chargers as a completely turn-key power solution for our customers.
Battery Material |
Lithium Ion Electric New Samsung Bottle Battery |
||||
Battery Pack Model |
36V12Ah ( With NCM Cells) |
48V10Ah (with NCM Cells) |
36V15Ah (With Samsung Cells) |
48V12Ah (With Samsung Cells) |
|
Outer Packing Material |
PVC, Plastic shell, Plastic and Aluminum Shell, Steel Sheel |
||||
Nominal Voltage |
36V |
48V |
36V |
48V |
|
Rated Capacity |
12Ah |
10Ah |
15Ah |
12Ah |
|
Max. Charge Voltage |
42V |
54.6V |
42V |
54.6V |
|
Normal Charege Current |
2A |
2A |
2-3A |
2A |
|
Cut-Off Discharge Voltage |
30V |
30V |
30V |
39V |
|
Max.ConstantDischarge Current |
20-25A |
20-25A |
20-25A |
20-25A |
|
Max.Discharge Current (pulse) |
65A |
65A |
65A |
65A |
|
Charging Model |
CC/CV (With USB Function) |
CC/CV (With USB Function) |
CC/CV (With USB Function) |
CC/CV (With USB Function) |
|
Cycle Life(80%DOD) |
800 Cycles |
800 Cycles |
1200 Cycles |
1200 Cycles |
|
Charge Temperature |
0-45°C |
0-45°C |
0-45°C |
0-45°C |
|
Discharge Temperature |
-20-55°C |
-20-55°C |
-20-55°C |
-20-55°C |
|
Motor Range |
36V350-500W |
48V350-1000W |
36V350-500W |
48V350-1000W |
|
Features:
A. Extremely safe and stable chemistry: PCB and/or BMS built inside to balance protect the battery.
B. Long life-cycle: Can be circularly used, best can up to 800 times recycles, 8 times of Lead acid battery.
C. Lighter weight, with the best power-to-weight ratio: 1/3 of Lead acid battery weight.
D. Good performance at high temperature and high temperature resistance
E. Low self-discharge rate, less than 3% monthly.
F. No memory effects and highly efficient charge.
G. Environment friendly: Clean and Green energy poses no pollution on our environment.
LITH POWER offers different lithium electric battery, like 36V10AH and 36V12AH samsung cells bottle battery, for 36V350-500W motor bikes, 48V10A and 48V12Ah samsung cell electric bike tube battery for 48V500W motor bike and 48V1000W electric bicycle bottle/tube bike battery with USB charge port.
♣ Long lifecycle: more than 2000cycles with 1C rate, nearly 8 times of lead acid battery.
♣ Low self-discharge: < 3% monthly
3C |
LiFePO4 |
Lead Acid |
Ni-Cd |
Ni-Mh |
Self-discharge/month |
less than 3% |
10% |
13%~15% |
25~35% |
♣ High power output
♣ No memory effect: can be recharged efficiently with no reduction of capacity.
♣ Wide working temperature range: -20~65°C
♣ Lighter weight and smaller dimension: 1/2 size and 1/3 weight of lead acid battery, 70% size of Ni-MH Ni-Cd battery
Application
♣ Electric propelling applications: engine starting battery; Slow Speed Car; intellectual robots; electric bicycle/motorcycle/scooter; golf trolley/carts/ sightseeing car; power tools.
♣ Energy storage: solar and wind power system; city on/off grid; community and family, RV Caravan, Marine yachts.
♣ Back-up system and UPS: telecom base, CATV-system, computer server center, medical instrument, military equipment.
♣ Other applications: security and electronics; mobile POS, mining light/torch/LED light/emergency light.
Excellent service
1.2 years' warranty on our LiFePO4 Battery
2. Fast Delivery service.
3. Quick response to your any inquiry within 12 hours.
4. Customized design is available, OEM and ODM are welcome.
5. Shipment by Air Express (door to door service), by Air Flight and by Vessel, all Available.
6. Offer the highest quality with the best price.
7. Professional Pre-sales service with Whole-hearted After-sales service.
Your inquiry will be warmly welcomed, looking forward to our long term cooperation.
