1.3M 960P Array IR Led IP Camera, Real Time,H.264

Name: 1.3M 960P Array IR Led IP Camera, Real Time,H.264
Brand: Thanks
SKU: 101160769
Availability: InStock

US$ 20 - 30 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Thanks

Model Number:

AK-1000N130

Guangzhou Thanks Electronic Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Thanks

Model Number AK-1000N130

Type Analog Camera

Style Bullet Camera

Sensor CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

Feature

1/3" 1.3 Megapixel High resolution CMOS,Max image Resolution 1920*720p@25fps
Super wide Dynamic range and 3D noise reduction
H.264 Main Profile @ level 3.0 coding, Real time H.264 dual-stream encoding, resolution, frame rate, bit rate adjustable
Support Color/BW mode converting, IR-CUT Filter
Build in Motion Detection, support alarm linkage,
bi-directional real time audio transmission and alarm input and output is optional
auto-retrieve function and auto-connection network
Poe is optional
Support Plug-and-Play, including PC surveillance platform and mobile client, Easy toremote
Integrated ONVIF standard, Compatibility with third-party ONVIF platform software

Specifications

Model	AK-1000N130
Hardware
Processor	GM8126
Sensor	1/3" 1.3 Megapixel high definition CMOS
Lens	12mm CS lens
IR LED	4pcs IR Array LEDs, IR Distance 80m
Day/Night	IR-CUT
Min. Illumination	0.5lux; 0 lux with IR on
Max S/N Ratio	50dB
Video
Compression	H.264
image	main stream: 1920x1080@1-25fps 1280x1080@1-25fps sub stream: 640x480@1-25fps 320x240@1-25fps
Bit Rate	128~4096kbps, Supports CBR/VBR
Image Control	Hue, saturation, brightness, contrast, exposure
Auto Image Control	AE, AWB
Audio(Optional)
Compression	G.711-A
Bit Rate	64kbps/128kbps
Talkback	support
Network
Protocol	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, FTP, UPNP
Compliance	ONVIF 2.1(1.02 backward compatible)
PC Client and Browser	ISS, IE6.0 and above
Interface
LAN	1 RJ45 10M/100M Ethernet port
General
Working Temperature	-10°C~ +55°C
Working Humidity	0% - 90%
Protection Level	IP66 Rated Waterproof
Power Supply	DC 12 V/1A
Power Consumption	Maximum 6w
Dimensions	260*120mm
Weight	2KG
Approvals	CE , FCC, RoHS
