Help CenterAll in One Packag 48v1000w Electric Motor Kit for 48v 1000w Electric Bike With 48v 20ah Lithium Battery
Related Products
-
48v1000w Bafang Bbs03 Mid Drive Motor Kits and 48v 1000w 8fun Mid-drive Central Motor KitUS$ 500.00 - 500.00MOQ: 5 Sets -
Bafang 48V1000W 8FUN Center Motor BBS-03 48v 1000w Electric Bike Motor With 48v 20ah Lithium Bike BatteryUS$ 500.00 - 500.00MOQ: 5 Sets
-
Hot Sales 8fun 48v 500w Electric Bike Motor Kit With 48v 12ah Samsung Downtube Battery for 48v 500w Central Electric Bike KitUS$ 200 - 480MOQ: 1 Set
-
Hot Sales 8fun 48v 1000w Electric Bike Motor Kit With 48v 20ah Lithium Rear Rack Battery for 48v 1000w Central Electric Bike KitUS$ 500.00 - 500.00MOQ: 5 Sets
-
Hot Sales 8fun 48v 1000w Electric Bike Motor Kit With 48v 20ah Lithium Battery for 48v 1000w 8fun Electric Bike KitUS$ 500.00 - 500.00MOQ: 5 Sets
2015 Latest Design Super Powerful RisunMotor Bafang/8fun 48V1000W Brushless Geared Mid-Drive Motor Conversion Kits with integrated Controller and C961/C965 LCD Display-MM G32.1000
2015 Newest RisunMotor/Bafang/8fun Brushless Geared Mid-Drive Motor Conversion Kits, controller integrated, If you want to know how you can spend a lot of money on an electric bike and get the ultimate in efficiency and performance this is a good start. MID drives are not the easiest or the cheapest electric bikes to build, but can be the cream of the crop once you are out riding, especially off road, especially climbing hills or even mountains......
With an integrated speed sensor, this mid-drive motor, which is compatible with a 68-120mm bottom bracket, has a rated power of 750-1000W, a reduction ratio of 1: 21.9 and a maximum torque of 160 N.m, will provide the rider with great explosive force when starting the system. Highly strong and efficient, this motor greatly enhances riding joy and is suitable for mountain bikes and sand bikes which are the favorites of riders who love challenges as well as transport bikes. This motor is black.
And we also offer the matched 48v 20ah lithium ion battery in rear rack type, suitable for 48V 1000W high power motor and with a matched 48V3-5A lithium charger as a complete power solution. 8Fun 48v 1000w mid-drive motor trike kit with 48v 20h lithium battery, bafang bbs03 48v 1000w central motor trike kit and 48v 1000w bbs03 mid- drive motor trike kit.
SPECIFICATIONS
Core Data
Position: Mid Motor
Construction: Geared Motor
Nominal Voltage: 36/48 V
Rated Power: 750-1000 W
RPM: 130-150
Max Torque: 160 N.m
Efficiency: ≥ 85 %
PAS SENSOR: Speed sensor
Shaft Standard: JIS
Mounting Parameters
Weight: 4.8 kg
Further Specifications
Cadence (Pulses/Cycle): N/A
Reduction Ratio: 01:21.9
Magnet Poles: 8
Noise: < 55 dB
Hall Sensor: optional
Connector: Waterproof
Tests & Certifications
IP-Code: IP 65
Certifications: CE / UL / ROHS EN 14764
Dimension A: 215mm
Dimension B: φ210mm(46T)
Dimension C: 123mm
Dimension D: 68 / 100 / 110 / 120mm
Dimension E: 175/190/200/210mm
Dimension F: 50 / 65 / 70 / 75mm
Dimension G: 88 / 103 / 108 / 113mm
With an integrated speed sensor, this mid-drive motor, which is compatible with a 68-120mm bottom bracket, has a rated power of 750-1000W, a reduction ratio of 1: 21.9 and a maximum torque of 160 N.m, will provide the rider with great explosive force when starting the system. Highly strong and efficient, this motor greatly enhances riding joy and is suitable for mountain bikes and sand bikes which are the favorites of riders who love challenges as well as transport bikes. This motor is black.
All in one packag 48v1000w electric motor kit for 48v 1000w electric bike and also 48v 20ah lithium rear rack battery available
