4 Channel AHD CCTV DVR
storage/3G dialing /P2P/PNP/FTP
2.D1/HDMI/960H/Real time/H.264
AHD 4 Channel CCTV DVR
1 Support PC and Smartphone playback
2 The unique data storage technology, which can record the data of 1 sec before power failure
3 Support composite streaming and video streaming encoding. Under the composite steaming encoding,
video and audio can be encoded synchronously
4 Support VGA, BNC and HDMI output
5 High definition VGA display, 800*600, 1024*768, 1280*1024
6 Support digital zoom in preview and playback
7 Support different PTZ protocols, support present tour function
8 Activates event recording automatically when alarm is triggered, and send alerts with images to designated emails
| Model | AK-ADVR7004R-LM | |
| System | GUI: | Graphic User Interface(OSD Menu) |
| Operation system: | Linux(embedded) | |
| Multiplex Operation: | Pentaplex : Preview, record, playback, backup, network | |
| Video/ Audio input | password security : | Multi-user management operation |
| Analog video input: | 4CH,BNC, 1.0p-p, 75Ω, | |
| Audio input: | 1CH, RCA, 2.0Vp-p,600kΩ | |
| Video/Audio output | HDMI Output: | support |
| VGA output: | 1CH, resolution: 800*600, 1024*768,1280*1024 | |
| Display: | 1ch / 4ch optional | |
| Video standard: | PAL/NTSC | |
| CVBS Output: | 1CH,BNC, (1.0Vp-p,75Ω) | |
| Resolution: PAL (704*576), NTSC(704*480) | ||
| Audio output: | 1CH, RCA, (Linear electrical level, 600Ω) | |
| Video/Audio encoding parameters | Video compression: | H.264 |
| Display frame rate: | PAL: 100fps (4 x 25 fps)NTSC: 120fps (4 x 30 fps) | |
| Record frame rate: | PAL: 100 fps(4 x 25 fps) NTSC:120 fps(4 x 30 fps) | |
| video coding resolution: | 4CIF(704X576) | |
| video frame rate: | 1-25FPS | |
| video bit rate: | changeable and fixed bit rate(optional) | |
| Stream type: | composite/ video | |
| Audio compression: | ADPCM | |
| Recording Mode: | Support normal / timer / alarm / motion detection recording | |
| search video files : | By time period / channel / video type | |
| Audio bit rate: | 8-32kbps | |
| Dual steaming: | support | |
| Mobile phone monitoring: | Android / iphone / blackberry / windows / symbian | |
| Recording resolution: | Recording: 4ch D1 Playback: 4ch D1 | |
| Synchronous Playback: | 4ch | |
| Hard Disk Driver | Type: | 2 SATA interface |
| capacity: | Maximum 3TB HDD | |
| recording type(Audio) : | audio and video recording simultaneously | |
| remote control /mouse | support | |
| Network: | Support IE/PPP0E/DDNS, DHCP,DDNS,PPPoE, IE view, and CMS central control | |
| NAT | Support | |
| Network interface: | 1 RJ45 10M/100M, adaptive Ethernet interfaces | |
| Serial interface: | 1 standard RS-485 serial interface | |
| interface: | 2, USB 2.0 | |
| software upgrade: | Support USB/ network upgrade | |
| Others | Power supply: | DC12V@2A |
| consumption(without HDD) | ≤15W (Without HDD) | |
| Working Temperature: | -10°C--+55°C | |
| working Humidity: | 10%--90% | |
1. Any inquiries will be replied within 24 hours.
2. OEM/ODM available:
1) Silk print logo on camera & DVR
2) Customized camera housing
3) Customized Color box
4) Any your idea on camera we can help you to design and put it into production
3. High quality, fasion designs, reasonable & competitive price, fast lead time.
4. After-sale service.
1) All products will have been strictly quality checked in house before packing
2) All products will be well packed before shipping.
3) All our products have 2 years warranty.
5. Fast delivery:
Sample order about 4 working days, and 7-10 days for bulk production.
6. Payment:
You can pay for the order via: T/T, Western Union, Paypal & L/C
7. Shipping:
We have strong cooperation with DHL, TNT, UPS, Fedex, EMS, China Post.
You also can choose your own shipping forwarder, by air or by Sea.
Thanks Electronics Limited is a professional CCTV manufacturer in Guangzhou, China. Since its foundation in 2002, we are doing our best to be top security supplier in China.
Our products include Analog camera, HD Analog Camera, IP camera, DVR, NVR,etc. And our products are with the certifications of CE, FCC, RoHS.
Our products are exported to many countries and regions, Asia, North American, UK, AU, Middle East, Brazil, South Africa and so on.
Choos Thanks Electronics Limited, Choose your best business partner!
