MDF Board UV Laminating Machine TJ-PD1320

Name: MDF Board UV Laminating Machine TJ-PD1320
Brand: JINGYUAN
SKU: 101146405
Availability: InStock

US$ 7,000 - 7,500 MOQ: 1 Set

Key Specifications

Condition:

New, New

Application:

Other, Chemical, Building materials, MDF board,Ceramic, Aluminium, Chemical, Glass,wood,arylic,etc

Packaging Type:

Case, Other, Case, plywood case

Shenzhen Jingyuan Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Foshan

Delivery Detail:

Delivery time depends on order quantity.

Application Other, Chemical, Building materials, MDF board,Ceramic, Aluminium, Chemical, Glass,wood,arylic,etc

Packaging Type Case, Other, Case, plywood case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Other, Electric, Electric

Voltage 220V

Power 2500W

Place of Origin Guangdong, China

Brand Name JINGYUAN

Model Number TJ-PD1320

Dimension(L*W*H) 5000*1880*1800mm, 5000*1880*1800mm

Weight 600kg

Certification CE, CE

After-sales Service Provided No overseas service provided

Jingyuan Technology Co.,Ltd

1, Product information:

MDF board UV laminating machine TJ-PD1320

Technical parameters
Technical parameters
Model	Effective working width	Effective working height	Minimum length of processing	feeding speed	rubber roll power	Dimensions
TJ-PD650	650mm	2-70mm	300mm	50-300mm/min	1.75kw	320012001800mm
TJ-PD1320	1320mm	2-70mm	300mm	50-300mm/min	2.5kw	500018801800mm

Suitable for coating the film on the MDF board, Ceramic, Aluminium, Spray painting, graphic printout, photo studio, printing industry, building materials industry, PVC sheet, acrylic, tiles, glass, wooden doors etc.
Comparing with other liquid laminating machine. this machine is more simple to use, and more environmental , and cheaper

2, Advantages:

Advantages	1,Wide processing thickness. Wide range of applications
	(suitable for acrylic, mdf boards, flat Furniture, ceramic tiles, marble, wood flooring, a flat-screen doors, aluminum ceiling,organic board)

	2,imported high quality spray head, Reliable Quality, easy to adjust the size of the muzzle according to customer demand, to achieve the best results use

	3, Automatic detection of material, automatic start gun, automatic stop working, fully automated work

	4,This machine is equipped with a UV oil circulation device, UV oil recovery is quick and easy, no waste, and to install UV oil filtration device, can effectively eliminate air bubbles and ink pollutants
	5,Imported inverter, so that the paint smoothness, more precise control of film thickness
	6, Single operation, HMI, health, clean, high efficiency

	7,Low cost, high efficiency
