veterinary hospital radiography high frequency 200mA medical animal x-ray machine
- 1000 Set / Sets per Month
- Guangzhou China for medical animal x-ray machine
- T/T Credit Card PayPal
- high frequency general radiography and obtain clear images 200mA vet medical x ray equipment
- reasonable price fast delivery time 200mA radiography veterinary medical x ray device
- high quality imaging 20kw high frequency pet medical x-ray machine
- Top quality hot sale 20kw 200mA cheap animal medical x-ray equipment price
- 200mA high quality lowest price pet clinic veterinary medical x ray equipment
- good selling good price 100kV 200mA 20kW radiography vet medical x ray machine
Product Details
Properties: | Other, Medical X-ray Equipments & Accessories | Brand Name: | YUESEN-MED | Model Number: | YSX200G |
Place of Origin: | China |
Packaging Details
standard export package of medical animal x-ray machine
Product Description
veterinary hospital radiography high frequency 200mA medical animal x-ray machine
Model:YSX200G
Features for 200mA radiography veterinary medical x ray device
1. 20KW//30KHz: High frequency machine can cover all body parts, undertake general radiography and obtain clear images.
2 If you have mobile DR flat, that will be fantastic! A slight upgrade can help you realize direct digital imaging.
3. Its solid & streamline shape, as well as its ultra-long service life, make it well worth the cost.
4. Various parameter-setting keys: You can select kV, mA and mAs to set the desirable radiography conditions. With quick human body parts programming, it simplifies the operation procedures. Capacity protection can be fulfilled by locking the three-parameter option keys, according to the capacity constraint of x-ray tube.
5. High precision control mode through analog & digital double-loop control: Adopting HF (≥30kHz) inverter circuit combined with analog & digital double-loop control mode (composed of microprocessor and PWM dedicated chip), in order to achieve high-precision high voltage output. Power supply fluctuation may occur, but there is still steady x-rays output.
6. High precision control in radiography time: Minimum exposure time is 0.0025 second, and quick radiography is accessible at any time without the influence of power phase, thus high-quality images are easily achieved and radiation to patients is minimized.
7. Self-protection & self-diagnosis: Once malfunction occurs, generator will self-protection and give an alarm. The malfunction can be detected via error code, and it’s convenient for maintenance.
8. High-precision tube current control: The heating of x-ray tube adopts dual-stage high frequency converter, through taking sample tube current by high-speed running A/D converter and implement real-time control through micro-processor. The micro-processor controls the safe load of x-ray tube, and the best radiographic conditions can be set.
9. Compact structure, reduce installation space.
Technical index of main component:
CONTENTS | YSX200G | |
Intermittent mode | 100kV ,200mA,20kW | |
Power Voltage | 380V±10% 50Hz±10% |
|
Tube current | Radiography 16mA~200mA |
|
Output Voltage | Radiography 40-125KV step 1kV; |
|
Resistance power | less than 0.5Ω. |
|
Output power | 20kW |
|
Exposure Time | Radiography 0.0025s~6.4s adjustable |
|
Nominal Frequency | 30kHz | |
Speed of anode rotating | 2800r/min | |
Anode heat capacity | 140KHU |
|
Focus | Small focus:1.0mm Big focus:2.0mm | |
Length*width*height of bed surface | 2000mm×750mm×690mmDeviation:±10mm | |
Horizontal movement distance of table | ≥200mm | |
Vertical movement distance of table | ≥900mm | |
Distance from table surface to film | 50mm±2mm | |
Distance of vertical movement | 770mm±10mm; |
|
Moving crosswise (left & right) | +180°~-180°deviation<±2° | |
Moving lengthways (along ground railway) | ≥1300mm |
|
Fixed beam filtration grid density | ≥40 lines/cm. | |
grid ratio | 10:01 | |
Focus Distance | 100cm | |
Cassette size | 5″×7″ 8″×10″ 10″×12″ 11″×14″ 14″×17″. |
Configuration:veterinary x-ray equipment price
No | Part Name | Qty |
1 | X-ray tube | 1 |
2 | Radiographic Table | 1 |
3 | Collimator | 1 |
4 | Microcomputer console | 1 |
5 | High-voltage generator, | 1 |
6 | High voltage cable | 2 |
7 | Vertical bucky stand | 1 |
veterinary medical x ray machine
veterinary medical x ray machine
good selling good price 100kV 200mA 20kW radiography vet medical x ray machine
veterinary hospital radiography high frequency 200mA medical animal x-ray machine
