Top quality made in China best price medical monitoring systems

standard package of medical monitoring systems

Top quality made in China best price medical monitoring systems

Features:medical monitoring systems
12.1' inch colored, high definition TFT screen
Lightweight, compact and portable
Parameters: SPO2, ECG, NIBP, TEMP, RESP
Suitable for DOG, CAT and HORSE etc.
72 hours graphic and tabular trends of all parameters
32 seconds full-disclosure waveform review
500 NIBP measurement data can be stored and recalled
Storage and recall of 500 SpO2 measurement data
Built-in rechargeable Lithium battery

Technical Specifications:medical monitoring systems
1. Parameters: SPO2, ECG, NIBP, TEMP, RESP, PR, RR. Optional function: ETCO2 and internal printer.

2. Power supply
AC power adapter, AC 85~265V/ 50Hz/60Hz;
lithium battery.

3. SpO2
Range: 0%-100%.
Accuracy: ±2% at 70-100%;<70%, undefined.

4. Pulse rate
Range: 30-250bpm.
Accuracy: ±2bpm at 30-250bpm.

5. NIBP
Method: Oscillometry
Modes: Manual/Auto/Comtinuous
Auto measure time: Adjustable
Measurement range: 10-270mmHg

6. ECG
Lead mode:3-lead or 5-lead
Lead selection:I;II;III,avR;avF;V
Heart rate range:Adult:15-300bpm;Pediatric/Neonatal:15-300bpm
ECG waveform:2 channals
Accuracy: ±1 bpm or ±1%,which is greater
S-T segment detection;measurement range: -2.0mv~2.0mv
Alarm:Yes,audible and  visual alarm,alarm events review

7. Respiration
Method:RA-LL impedance
Range:Adult:0-120rpm;pediatric/neonatal:0-150rpm
Apnca alarm:Yes

8. Temperature
Range:0-500C
Accuracy: ± 0.10C
Channel: Dual-channel

Environment Specification:medical monitoring systems
Operating Temp.: 0 to 45°c
Storage Temp.: -20 to +60°c
Relative Humidity: 30 to 95%(Operating), 10 to 95%(Storage)

Standard Package:medical monitoring systems
HK-M5000V  Main Uint
Veterinary SpO2 Probe
5-leads ECG Cable (mini clip)
NIBP Cuff for VET
NIBP Extension Tube
Power cable
Battery
User manual
