Specifications
1.FTTB fiber optic receiver low price2.Small size wall type
3.Frequency Range 45/87 ~ 750/862
4.2MW
5.Adopt GaAs
Name of this optical receiver: FTTB fiber optic receiver low price with high quality
Description
RDH8622 optical receiver is specialized in response to FTTH - Fiber to the home network of the group structure
introduced specialty products. This product has a high cost-effective, low-distortion, low power, high reliability,
small size, compact structure and the internal circuitry is reasonable, excellent performance.
Products are suitable for schools, hospitals, commercial centers,residential, home users, is the first choice for FTTH
optical networking products.
Technology Parameters
Item |
Unit |
Parameter |
Forward Performance Parameter | ||
Optical Parameter | ||
Receive Optical Power |
dBm |
-7 ~ +2 |
Propose Use Range |
dBm |
-3 ~ +1 |
Return Loss |
dB |
> 45 |
Optical Wavelength |
nm |
1100 ~ 1600 |
Connector Type |
|
SC/APC |
Fiber Type |
|
Single Mode |
Circuit Performance | ||
C/N |
dB |
≥ 50 |
C/CTB |
dB |
≥ 65 |
C/CSO |
dB |
≥ 62 |
RF Parameter | ||
Frequency Range |
MHz |
45/87 ~ 750/862 |
Flatness in Band |
dB |
±0.75 |
Rated Output Level |
dBμV |
≥ 85(-2dBm) |
Max Output Level |
dBμV |
≥ 90 |
Output Return Loss |
dB |
≥ 14 |
Output Impedance |
Ω |
75 |
Return Transmit Performance Parameter | ||
Optical Parameter | ||
Optical Transmit Wavelength |
nm |
1310±10 |
Laser Type |
|
FP Laser |
Output Optical Power |
mW |
0.5 ~ 2 |
Connector Type |
|
SC/APC |
RF Parameter | ||
Frequency Range |
MHz |
5 ~ 30/65 |
Flatness in Band |
dB |
±1.5 |
Input Level |
dBμV |
80 ~ 90 |
Input Return Loss |
dB |
≥ 16 |
Output Impedance |
Ω |
75 |
Principle drawing
1) Welcome to order on the alibaba Wholesale Checkout Service,you can play order on line and pay,it's easy to do it.
2) For More Sport order,please contact us about your order with your demand and we give more competitive price to you and will send order invoice for you,after your confirm,and then make the payment,at last ship to you after the payment be confirmed.We keep big stocks every day!
3) OEM/ODM service available and custom designs are welcomed! We can offer you premium quality,competitive price,print your LOGO free ,Quality for your any request.
1) Sport order shipment time: we ship to you at 1-2 days (Depends on the Qty) after advanced payment received
2) Production time:7-15days with OEM order (Depends on the Qty) after advanced payment received
3) Shipping ways: ship by Fedex,DHL,UPS,TNT,EMS,Hong Kong Airmail Post,China Post Air and so on.
1) Escrow on line
2) Paypal
3) T/T ( Bank Transfer)
4) Western Union
5) Credit card
For Large quantity or OEM order service, 30% first, 70% balance before delivery.
we offer more buyer protection for you,so you don't worry about your order:
1) Full Refund if you don't receive your order
2) Refund or Keep items not as described
If you need optical receiver,please contact with me without hesitation.
