2.4G Wireless Adaptor
Technical details
Product Name |
WLAN 11n USB 1T1R Dongle |
Model |
BIO-U101 |
Major Chipset |
MT7601U |
Frequency Band |
2.4~2.4835 GHz ISM Band |
Standard |
802.11b/g/n, 802.3, 802.3u |
Receiver Sensitivity |
11Mbps-86dBm@8%, |
Data Transfer Rate |
1,2,5.5,6,11,12,18,22,24,30,36,48,54,0,90,120 |
Modulation Method |
BPSK/ QPSK/ 16-QAM/ 64-QAM |
Operation Mode |
Ad hoc, Infrastructure |
Security |
WEP, TKIP, AES, WPA, WPA2 |
Operation Range |
Up to 180 meters in open space |
Power Consumption |
DC-5V Maximum power dissipation in 80MA |
| RF Output Power | < 13dBm@11n,< 14dBm@11g,< 18dBm@11b |
| OS Support |
Windows 2000,XP32-64, Vista 32/64,Win7 32/64,Linux, |
| LED | NO |
| Interface | USB 2.0 |
| Dimension | L33mm*W18mm*H8mm |
