Brand Name KOYO
Bore Size 0, 20
Outside Diameter 0, 40
Model Number 51204
Precision Rating P0/P6/P5/P4/P2, P0 P6 P5 P4 P2
Seals Type Open
Number of Row Single Row
Place of Origin Japan

KOYO Ball Bearing 51204 Thrust Ball Bearing 51204 Vertical Pump Bearing Sizes 20*40*14mm

KOYO Ball Bearing 51204 Thrust Ball Bearing 51204 Vertical Pump Bearing Sizes 20*40*14mm

Thrust Ball Bearing 51204 Information

Brand Name

SAIFAN KOYO Bearing or according to your requirement

Model Number

Thrust Ball Bearing 51204

Bore Sizes

20mm

Outside Diameter

40mm

Bearing Weight

0.0733kg

Material

Chrome steel, Gcr15

Vibration Level code

V1,V2,V3,V4

Precision

P0,P6,P5,P4,P2

Cage Type

Brass Cage,Steel Cage,Nylon Cage

Guarantee

50000km Or One year

Delivery Detail

3-10 days upon receipt of deposit

Shipping

Express: DHL Fedex EMS  /By Sea

Application

Applies only to withstand side of the axial load, the speed on the lower parts, such as crane hooks, vertical pumps, vertical centrifuge, jack, speed reducer and so on. Shaft bearing ring, seat ring and rolling elements are separated, you can dismantle respectively.



Thrust Ball Bearing Photos
KOYO Ball Bearing 51204 Thrust Ball Bearing 51204 Vertical Pump Bearing Sizes 20*40*14mmKOYO Ball Bearing 51204 Thrust Ball Bearing 51204 Vertical Pump Bearing Sizes 20*40*14mmKOYO Ball Bearing 51204 Thrust Ball Bearing 51204 Vertical Pump Bearing Sizes 20*40*14mm

1.The Features of Thrust Ball Bearing:

1. Equipped with one-way, two-way two types

2. In order to allow the installation error, whether it is one-way or two-way, you can choose spherical self-aligning spherical seat type or spherical seat type.
3. High-quality steel - the use of bearing life extended up to 80% of the super-clean steel
4. The height of grease technology - grease lubricant technology can extend the life and improve bearing performance
5. High-grade steel ball - quiet and smooth high-speed rotation
6. Use of options in the ring, may allow the installation error.

2.The Species of Thrust Ball Bearing:
By the force of sub-way and two-way thrust ball bearings thrust ball bearings.
Thrust ball bearings can withstand axial load.
Thrust ball bearings can withstand axial load, wherein the shaft and the shaft with the ring. Appear before the installation of seat spherical bearings with aligning properties, can reduce installation errors.
Thrust ball bearings can bear radial load, lower speed limit.

3.Thrust Ball Bearing Introductions:

Thrust ball bearings can withstand high speed thrust load design, the washer-shaped ball rolling with a rolling groove ferrule constituted. Since the saddle-shaped rings, therefore, thrust ball bearings are divided into flat seat type and self-aligning spherical seat of two types. In addition, the bearings can withstand axial load, but can not bear radial load.

4.The Components of Thrust Ball Bearings:
Thrust ball bearings from the seat, shaft ring and ball cage assembly of three parts.
And the shaft with the axis of said ring, and the shell with said seat.

5:Thrust Ball Bearings Application:

Applies only to withstand side of the axial load, the speed on the lower parts, such as crane hooks, vertical pumps, vertical centrifuge, jack, speed reducer and so on. Shaft bearing ring, seat ring and rolling elements are separated, you can dismantle respectively.

6:Related Thrust Ball Bearing Catalogue

Item

Size (mm)

Load rating (kN)

Limit speed (r/min)

Weight

d

D

T

Ca

Coa

Grease

Oil

(kg)

51100

10

24

9

10

14

6500

1000

0.02

51200

10

26

11

12.7

17.1

5700

8800

0.03

51201

12

28

11

13.2

19

5400

8300

0.034

51102

15

28

9

10.5

16.8

6100

9400

0.024

51103

17

30

9

10.8

18.2

6100

9400

0.028

51203

17

25

12

17.2

27.3

4900

7500

0.053

51104

20

25

10

14.2

24.7

5100

7900

0.04

51304

20

47

18

35

55.8

3600

4500

0.092

51105

25

42

11

19.5

37.2

4400

6800

0.059

51305

25

52

18

35.7

61.4

3100

4800

0.18

51405

25

60

24

55.6

89.4

2600

4000

0.34

51106

30

47

11

20.4

42.2

4300

6600

0.068

51306

30

60

21

42.8

78.7

2700

4200

0.27

51307

35

68

24

55.5

105

2400

3700

0.39

51408

40

90

36

113

205

1700

2600

1.14

51209

45

73

20

47.7

105

2600

4000

0.32

51309

45

85

28

80

163

1900

3000

0.69
