Home > Lights & Lighting > LED Interior Lighting > LED Down Light > INNOVALIGHT 9W/12W Sharp COB Waterproof Fire Rated Downlight
INNOVALIGHT 9W/12W Sharp COB Waterproof Fire Rated Downlight
US$ 10 - 20
MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
COB
Warranty(Years):
3
Input Voltage(V):
AC 220V-240V
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
INNOVALIGHT GU10 Version Terminal Block IP65 Fire Rated DownlightUS$ 1 - 4MOQ: 1 Piece -
INNOVALIGHT LED GU10 MR16 Round Iron Fire Rated Downlight Fixture Quality ChoiceUS$ 1 - 4MOQ: 10 Pieces
-
INNOVALIGHT Hot Sales in UK GU10 Fire Rated Downlight IP65 DownlightUS$ 1 - 4MOQ: 1 Piece
-
INNOVALIGHT 95mm Cut Out Square Recessed Downlight 12W IP65 LED DownlightUS$ 5 - 12MOQ: 1 Piece
-
INNOVALIGHT High Lumen Round Square Shape IP65 LED Down LightingUS$ 5 - 12MOQ: 1 Piece
LED Light Source
COB
Warranty(Years)
3
Input Voltage(V)
AC 220V-240V
Lamp Power(W)
9
Lamp Luminous Flux(lm)
844
Lamp Luminous Efficiency(lm/w)
90
Color Temperature(CCT)
Warm White
Working Temperature(℃)
-20, 50
Working Lifetime(Hour)
30000
Lamp Body Material
Aluminum
IP Rating
IP65
Certification
CCC, SAA, SASO, VDE
Model Number
INN-FR-9W
Place of Origin
Guangdong, China
Brand Name
INNOVALIGHT
Fire Rated Downlight
Product Description
1.High brightness, stable performance, long life span, widely used ,low power consumption, energy savings and environmental protection.
2.Die casting aluminum housing with good finish,optical Grade PMMA lens.
3.No UV or other radiation,Instant start;no flickering,firm colour temperature .
4.IP65 Rated.
Features
| Commercial Fire-rated down light 9 W | |||||
| Total Power | 9W | Input Voltage | AC 220V-240V | ||
| Led Brand | Sharp | Led | Sharp COB | ||
| Output current | 220mA | Power Factor | >0.90 | ||
| Driver Protections | short circuit/over load/over voltage/over temperature | ||||
| Luminous Flux | 3000K | 844lm | Operating Temp. | -5℃~50℃ | |
| 4000K | 895lm | Efficiency | >80% | ||
| 5000K | 920lm | Color Difference | <4.5 | ||
| Finish Color | White | Cut out | dia 83mm | ||
| Shell Material | Aluminum | IP Grade | IP65 | ||
| CRI | Ra>80 | Color | 3000K/4000K/5000K | ||
| Lifespan | >40000 hours | Warranty | 3 years | ||
| Model | FPD1137W | Light Angle | 24° | ||
| Model | FPD1138W | Light Angle | 38° | ||
| Model | FPD1139W | Light Angle | 60° | ||
| Dimension/Size | Diameter 90mm * Height 93mm, cut hole 83mm | ||||
| Certification | CE/ROHS | ||||
| Neutral Packing Information | |||||
| Unit N.W. | 0.349kg | White box Size | 525*380*260mm | ||
| G.W/CTN | 10.4kg | Unit/CTN | 8.4kg | ||
Application
Interior/Indoor lighting projects, Commercial Lighting projects.
Shopping malls, offices, hotel halls, showrooms, Schools,hotels/restaurants, reception rooms, Meeting rooms
theaters, dinning rooms, Bedrooms, corridor, living rooms..
Our Services
After-sales Services:
1.Two years warranty
2. Comolain-Reply will be in 24 hours
3.Any help needed in China please call us (24hours)
