High Oil Resistant High Pressure High Temperature Rubber Hose
Related Producets
HENGSHUI YATAI ESPECIAL RUBBER PRODUCTS CO.,LTDis established in 2001 year.
QUALITY IS OUR COMPANY SOUL!!!
MAIN PRODUCT TYPE |
PRODUCT DETAILS |
Hydraulic Hose and Fitting |
Steel Wire Braided Reinforcement Hose(R1 R2 1SN 2SN 1SC 2SC R16 R17) |
Steel Wire Spiral Reinforcement Hose(2SP 4SP 4SH 6SP R9 R12 R13 R15) | |
Fibre Braided Covered Hose (R5) | |
Acid and Alkali Resistant Rubber Hose | |
Air Screw Compressor Hose | |
Middle Pressure Fibre Reinforcement Hose(R3 R6 1TE 2TE 3TE) | |
Thermoplastic Hose(SAE100R7 SAE100R8) | |
Nylon Hose(Single and Double Hose) | |
Industrial Hose |
Air/Water/Oil/Fuel/Steam/Chemical Suction and Discharge Hose |
Special Hose |
Concrete Pump Hose, High Pressure Drilling Hose, Inflatable Packers |
Machine Equipment |
Crimping Machine, Cutting Machine |
High Oil Resistant High Pressure High Temperature Rubber Hose
StructureandCapability:
ThiskindofhoseismadeofInnerTube(Nylon)
reinforcement(HighFlexibilityNylonorThermoplastic).
ItisEthereal,Flexible,andtheinnertubeisvetySmooth.
WithafewlossofPressure,thehoseresistanceoftheMediumflowingissmall,
ItalsoownsafineperformanceofAnti-chemicalandImpulse.
DINEN855R7/SAE100R7
| I.D | O.D | Workingpressure | Burstpressure | Bendradius | Weight | Length | |||
| inch | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m | metres |
| 1/8 | 3.3 | 8.5 | 17.2 | 2500 | 68.9 | 10000 | 13 | 0.037 | 20~100 |
| 3/16 | 4.8 | 10.8 | 20.7 | 3000 | 82.7 | 12000 | 20 | 0.068 | 20~100 |
| 1/4 | 6.4 | 13 | 20.7 | 3000 | 82.7 | 12000 | 33 | 0.085 | 20~100 |
| 5/16 | 7.9 | 15.1 | 17.2 | 2500 | 68.9 | 10000 | 46 | 0.103 | 20~100 |
| 3/8 | 9.5 | 17 | 15.5 | 2250 | 62.1 | 9000 | 51 | 0.141 | 20~100 |
| 1/2 | 12.7 | 20.7 | 13.8 | 2000 | 55.2 | 8000 | 76 | 0.21 | 20~100 |
| 3/4 | 19 | 27.1 | 8.6 | 1250 | 34.5 | 5000 | 127 | 0.287 | 20~100 |
| 1 | 25.4 | 34 | 6.9 | 1000 | 27.6 | 4000 | 203 | 0.542 | 20~100 |
DINEN855R8/SAE100R8
| I.D | O.D | Workingpressure | Burstpressure | Bendradius | Weight | Length | |||
| inch | mm | mm | MPa | Psi | MPa | Psi | mm | kg/m | metres |
| 3/16 | 4.8 | 13.1 | 34.5 | 5000 | 137.9 | 20000 | 38 | 0.115 | 20~100 |
| 1/4 | 6.4 | 15.9 | 34.5 | 5000 | 137.9 | 20000 | 51 | 0.176 | 20~100 |
| 3/8 | 9.5 | 19.4 | 27.6 | 4000 | 110.3 | 16000 | 64 | 0.22 | 20~100 |
| 1/2 | 12.7 | 22.7 | 24.1 | 3000 | 96.5 | 14000 | 102 | 0.283 | 20~100 |
High Oil Resistant High Pressure High Temperature Rubber Hose
High Temperature Rubber Hose Processing Procedures:
High Temperature Rubber Hose Exhibition and Certification:
Welcome to Inquiry for High Oil Resistant High Pressure High Temperature Rubber Hose
