1300mm width acrylic polishing machine
1300mm width acrylic polishing machine
The series characters:
1.for sanding and polishing all kinds of Paint.
2. has one head,two heads,one head with polishing pad, two types.
3. sanding width between 400mm to 2000mm.
This type characters:
The lacquer sanding machine is mainly used for: furniture, calcium silicate board, cabinet plate, decorative plates, composite materials, such as flat panel in the paint (resin paint, polyester paint, nitrocellulose, water-based paint) curing then sanding and surface fine polishing.
1.has one head with polishing pad
2.sanding and polishing Max.1300mm width.
3. Imported converter to adjust belt speed to meet all the requirements of lacquer sanding.
4. Feeding system adopts stepless motor, according to different work pieces, select the appropriate feed rate to ensure that the quality of the work piece sanding.
5. U.S. 3M polishing rolls and soft rolls effective combination, to further improve the quality of the paint surface polishing.
6. Pressure inadequate or broken belt or deviation will automatically stop working, the table automatically descend to ensure safety.
7. Dust clean device effectively remove static anddust. Cooling, extending belt life and improve the precision sanding.
Working Width (mm) |
1300 |
Working Thickness (mm) |
2.5-120 |
Sanding belt speed (m/s) |
Frequency Converter |
Sanding belt size (mm) |
1330*2200 |
Speed of Feeding Belt (m/min) |
6-38 |
Total Motor Power (kw) |
18.5 |
Working Air Pressure (Mpa) |
0.55 |
Consumption of compressed air(m3/min) |
1.5 |
Collecting -dust air (m/s) |
25-30 |
Overall Dimensions: (L x W x L)mm |
2700*2100*2000 |
Weight(kg) |
3500 |
One head with one pad
Polishing roller is 3M brand (America)
Details:
1. Front press roller use avoiding injuring workers 2.Emergency button for safety, it can stop at once
3. Better strong roller 4. Board digital thickness display
5. with brush for better cleaning. 6. Strong and better friction force conveyor belt.
Additional options.
1. Plc control (optional) 2. Automatic air blower on first belt and second belt (optional)
3. Vacuum table (optional)
Standard spart parts
Optional spart parts
Qingdao Sefe Trading Co., Ltd. is a subsidiary of Sefe Woodworking Machine Manufacturing Company.
We are specialized in manufacturing woodworking machines for many years in Qingdao China.
with over 30 years of experiences in woodworking machine and metalworking fields, we have developed various series of woodworking machines, such as sander machine, sliding table saw,hot press,Hydraulic clamp carrier and so on. The SF brand sander is the famous brand in China Market,which includs wide belt sander, lacquer sander, water sander, double side sander and brush sander.
In order to supply high quality product and excellent services, we are continually improving our products with the latest technologies according to the market prevailing requirements. In the past years, all our products has got CE and ISO certificate.
Production meeting everyday morning.
Production corner
Exhibiton
CE Certificate ISO Certificate
1. Give easy broken spare parts with machine.
2. Our technician will tell you how to deal with small problems.
3. If request, our technician can go to your place to solve problems.
1. The machine has been setted before leaving factory.
2. We will send some easy broken spare parts with the machine.
3. The min. order is 1 pc.
4.We have our own factory. If you want to invest or sell our machines in your market , we expect to cooperate with you.
