The series characters:
1.for sanding and polishing all kinds of Paint.
2. has one head,one head with polishing pad, two types.
3. sanding width between 400mm to 2000mm.
This type characters:
The primer sanding machine is suitable for wood floors, furniture, composite panels, solid wood doors and windows, crafts, antique floor primer sanding and fine polishing surfaces.
1. has one head with polishing pad
2. sanding and polishing Max.400mm width.
3. Imported converter to adjust the belt line speed, feeding system selected CVT.
4. U.S. 3M polishing rollers quality stable, height adjustable and easier to eliminate the phenomenon to improve paint stripes and get better polishing effect.
5. Using 25SH natural elasticity rubber to eliminate the phenomenon of white side stripes. with high precision and long life.
6. Dust clean device effectively remove dust. Cooling, extending belt life and improve the precision sanding.
7. Insufficient air pressure or belt broken belt, automatically shut down when the deviation, the table automatically drop to ensure safety.
Working Width (mm) |
400 |
Working Thickness (mm) |
2.5-110 |
Sanding belt speed (m/s) |
Frequency Converter |
Sanding belt size (mm) |
420*1720 |
Speed of Feeding Belt (m/min) |
5-20 |
Total Motor Power (kw) |
7 |
Working Air Pressure (Mpa) |
0.6 |
Dust absorbed (m3/h) |
5000 |
Consumption of compressed air(m3/min) |
0.5 |
Overall Dimensions: (L x W x L)mm |
500*800*2000 |
Weight(kg) |
550 |
Details:
1) Star delta starting on main motor
2) Digital thickness display
3) Feeding belt automatic entering
4) Protector for sanding elt break down and utension
5) Board thicknesss setting device
6) Emergeny button for safety , it can stop at once
7) Photoelectric and double contact cylicder control vibrating of abrasive belt along center
8) Front press roller use on way bearing avoid injuring workers
9 Vacuum table (optional)
10) Plc control (optional)
One head with one pad
Polishing roller is 3M brand (America)
Standard spart parts
Optional spart parts
Qingdao Sefe Trading Co., Ltd. is a subsidiary of Sefe Woodworking Machine Manufacturing Company.
We are specialized in manufacturing woodworking machines for many years in Qingdao China.
with over 30 years of experiences in woodworking machine and metalworking fields, we have developed various series of woodworking machines, such as sander machine, sliding table saw,hot press,Hydraulic clamp carrier and so on. The SF brand sander is the famous brand in China Market,which includs wide belt sander, lacquer sander, water sander, double side sander and brush sander.
In order to supply high quality product and excellent services, we are continually improving our products with the latest technologies according to the market prevailing requirements. In the past years, all our products has got CE and ISO certificate.
Production meeting everyday morning.
Production corner
Exhibiton
CE Certificate ISO Certificate
1. Give easy broken spare parts with machine.
2. Our technician will tell you how to deal with small problems.
3. If request, our technician can go to your place to solve problems.
1. The machine has been setted before leaving factory.
2. We will send some easy broken spare parts with the machine.
3. The min. order is 1 pc.
4.We have our own factory. If you want to invest or sell our machines in your market , we expect to cooperate with you.
