DIN EN 856 4SH Industrial Agriculture Machine Rubber hose and fittings
DIN EN 856 4SH Industrial Agriculture Machine Rubber hose and fittings
Hengshui Yatai Especial Rubber Products Co.,LTD is established in 2001 year.
MAIN PRODUCT TYPE |
PRODUCT DETAILS |
Hydraulic Hose and Fitting |
Steel Wire Braided Reinforcement Hose(R1 R2 1SN 2SN 1SC 2SC R16 R17) |
Steel Wire Spiral Reinforcement Hose(2SP 4SP 4SH 6SP R9 R12 R13 R15) | |
Fibre Braided Covered Hose (R5) | |
Acid and Alkali Resistant Rubber Hose | |
Air Screw Compressor Hose | |
Middle Pressure Fibre Reinforcement Hose(R3 R6 1TE 2TE 3TE) | |
Thermoplastic Hose(SAE100R7 SAE100R8) | |
Nylon Hose(Single and Double Hose) | |
Industrial Hose |
Air/Water/Oil/Fuel/Steam/Chemical Suction and Discharge Hose |
Special Hose |
Concrete Pump Hose, High Pressure Drilling Hose, Inflatable Packers |
Machine Equipment |
Crimping Machine, Cutting Machine |
DIN EN 856 4SH Industrial Agriculture Machine Rubber hose and fittings
Tube : Oil resistant synthetic rubber
Reinforcement : Two,Four Six high tensile steel wire spiral layers
Cover : Abrasion and weather resistant synthetic rubber
Temperature range : -40 °c to 100 °c
4SH & 4SP Hydraulic Rubber Hose
| DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | |||
| inch | mm | mm | mm | MPa | psi | MPa | psi | mm | kg/m | |
| 10 | 3/8 | 9.5 | 17.5 | 21.4 | 45.0 | 6500 | 180.0 | 26000 | 180 | 0.78 |
| 13 | 1/2 | 12.7 | 20.2 | 24.6 | 41.5 | 6000 | 166.0 | 24000 | 230 | 0.93 |
| 16 | 5/8 | 15.9 | 23.8 | 28.2 | 35.0 | 5000 | 140.0 | 20000 | 250 | 1.17 |
| 19 | 3/4 | 19.0 | 28.2 | 32.2 | 35.0 | 5000 | 140.0 | 20000 | 300 | 1.48 |
| 25 | 1 | 25.4 | 35.5 | 39.7 | 28.0 | 4000 | 112.0 | 16000 | 340 | 2.02 |
| 32 | 1-1/4 | 31.8 | 46.0 | 50.8 | 21.0 | 3000 | 84.0 | 12000 | 460 | 3.05 |
| 38 | 1-1/2 | 38.1 | 52.4 | 57.2 | 18.5 | 2700 | 74.0 | 10800 | 560 | 3.52 |
| 51 | 2 | 50.8 | 65.3 | 69.8 | 16.5 | 2400 | 66.0 | 9600 | 660 | 5.20 |
DIN EN 856 4SH Industrial Agriculture Machine Rubber hose and fittings
Hydraulic Hose Exhibition:
DIN EN 856 4SH Industrial Agriculture Machine Rubber hose and fittings
DIN EN 856 4SH Industrial Agriculture Machine Rubber hose and fittings
Steel wire braided hydraulic hose Air compressor hose Gasoline hose
R3 R6 Fiber braided hydraulic hose Thermoplastic hydraulic hose LPG hose
