1. plywood cold press machine.
2. pre press for woodwork machine.
model |
BY814*8/4D |
BY814*8/5C |
Nominal pressure(KN) |
4000 |
5000 |
Unit pressure of board surface(Mpa) |
1.3 |
1.3 |
Width of press board (mm) |
2700 x 1370 |
2700 x 1370 |
Max. working stroke (mm) |
1000 |
1000 |
Net opening (mm) |
300-1300 |
300-1300 |
Diameter and quantity of pressure cylinders (mm) |
Φ 320/ 2 pieces |
Φ 360/ 2 pieces |
Diameter and quntity of lifting cylinders (mm) |
Φ 80/ 2 pieces |
Φ 80/ 2 pieces |
Feeding speed (m/min) |
6.78 |
6.78 |
Total motor power (kw) |
16.1 |
16.1 |
Overall dimensions (mm) |
3500×2400×4650 |
3500×2400X4750 |
1. Packing in Bulk or wood box.
2. Shipping: 20-30 days after deposit.
BASED ON MORE THAN TEN YEARS EXPORT EXPERIENCES IN WOODWORKING MACHINERY,WE OFFER A FULL LINE OF HIGH QUANLITY CHINA HOT PRESS,PRE-PRESS,SANDER,WOOD VENEER DRYER MACHINE
