NN100, NN150, NN200, NN250, NN300, NN400 , NN500, NN600
GB/T7984-2001, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etcTypes:
Besides General Nylon Belt, there are Fire-resistant type, Cold-resistant type, Wear-resistant type,
1) high abrasion resistance, high tensile strength and good fatigue resistance;
2) Conveyor belt with nylon canvas inside has the characteristics of thin belt body, high tensile strength, good shock resistance, good trough ability, high adhesion between plies, splendid flexibility and long working life.
Specification and technical data of polyester rubber conveyor belt
|
Fabric type |
Fabric structure
|
Fabric specs |
Ply Thickness (mm/p) |
strength (N/mm) |
Cover thickness (mm) |
Width (mm) |
Length (m) |
||||||
|
Wrap |
Weft |
2ply |
3ply |
4ply |
5ply |
6ply |
Upper |
Lower |
|||||
|
Nylon (NN)
|
Nylon (N) |
Nylon (N) |
NN-100 |
0.75 |
200 |
300 |
400 |
500 |
600 |
1.5 ~ 12 |
0 ~ 4.5 |
400 ~ 2200 |
≤300 |
NN-150 |
0.80 |
300 |
450 |
600 |
750 |
900 |
|||||||
NN-200 |
0.90 |
400 |
600 |
800 |
1000 |
1200 |
500 ~ 2200 |
||||||
NN-250 |
1.15 |
500 |
750 |
1000 |
1250 |
1500 |
|||||||
NN-300 |
1.25 |
-- |
900 |
1200 |
1500 |
1800 |
|||||||
NN-400 |
1.45 |
-- |
-- |
1600 |
2000 |
2400 |
800 ~ 2200 |
||||||
NN-500 |
1.55 |
-- |
-- |
2000 |
2500 |
3000 |
|||||||
Adhesion and elongation of the belt
Belt carcass |
Adhesion strength |
Elongation |
|||
|
Between plies N/mm |
N/mm Between rubber and carcass |
Longitudinal elongation elongation at break%≥
|
Longitudinal elongation at reference load%≤
|
||
|
Cover thickness ≤1.5mm |
Cover thickness ≥1.5mm |
||||
Nylon canvas |
≥4.50 |
≥3.20 |
≥3.50 |
10 |
4.0 |
According to the customer’s requirements, the belts could be made into endless belt, and the covering
rubber could be made into pit, chevron and level type etc.
Production process for polyester rubber conveyor belt
Useage:
It is suitable for conveying materials at medium or long distance and under conditions of heavy load and high speed.
Our research and development center, test equipment
Certifacations
Our company and customers
For more details,please inquiry us!
