Heat Resistant Steel Wire Conveyor Belt for Pipe Grooving Machine

Name: Heat Resistant Steel Wire Conveyor Belt for Pipe Grooving Machine
Brand: Huayun
SKU: 101015905
Availability: InStock

US$ 20.6 - 54 MOQ: 50 Meters

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Huayun

Model Number:

steel wire conveyor belt

Baoding Huayun Conveyor Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name Huayun

Model Number steel wire conveyor belt

steel wire conveyor belt

Advantage of steel wire conveyor belt
1. High tensile strength:Steel cord conveyor belt is suitable for large span,long distance

transportation of materials

2. Small elongation in use:It need only a very short take-up stroke distance.

3. Small diameter of drive pulley:Steel cord conveyor belt body has a layer of longitudinally

arranged steel cords as its skeleton,and thus is resistant to flex fatigue.Therefore,drive

pulley of smaller diameter can be used to make the equipment smaller.

4.High adhesion between rubber and steel cord:The steel cords are coated with zinc on

their surface,and also the rubber used has the property of qood adhesion with steel cords.

Therefore,the rubber is tighrly adhered to the steel cords and is resistant to shock and

difficult to drop,so the rubber belts are long in life.

parameters of steel wire conveyor belt

strength of the belt specifications	ST 630	ST 800	ST 1000	ST 1250	ST 1600	ST 2000	ST 2500	ST 3150	ST 3500	ST 4000	ST 4500	ST 5000	ST 5400	ST 6300
longitudinal tensible strength	630	800	1000	1250	1600	2000	2500	3150	3500	4000	4500	5000	5400	6300
Maximal nominal diameter of the steel wire mm	3.0	3.5	4.0	4.5	5.0	6.0	7.2	8.1	8.6	8.9/9.1	9.7	10.9	11.3	12.3
Space bettween cord	10	10	12	12	12	12	15	15	15	15/17	16	17	17	18
Top cover thickness	5	5	6	6	6	8	8	8	8	8/8	8	8.5	9	10
Bottom cover thickness	5	5	6	6	6	6	6	8	8	8/8	8	8.5	9	10
Quality	18	19.5	21.5	22.2	26.1	33.1	35.3	41.1	45	45/45	51	59	62	65
Width specifications	Number of steel cords
800	75	75	63	63	63	63	50	50
1000	95	95	79	79	79	79	64	64	64	64/56	59	55	55	54
1200	113	113	94	94	94	94	76	76	77	77/68	71	66	66	63
1400	133	133	111	111	111	111	89	89	90	90/79	84	78	78	74
1600	151	151	126	126	126	126	101	101	104	104/91	96	90	90	85
1800		171	143	143	143	143	114	114	117	117/108	109	102	102	96
2000			159	159	159	159	128	128	130	130/114	121	113	113	107
2200						176	141	141	144	144/125	134	125	125	118
2400						193	155	155	157	157/137	146	137	137	129
2600						209	168	168	170	170/148	159	149	149	140
2800									184	184/160	171	161	161	151
