dc oil pump,dc fuel pump,12v diesel transfer pump

dc oil pump,dc fuel pump,12v diesel transfer pump

Model:  RA-EP-F12

Voltage :DC 12V & 24V
Power :190W 1/4hp
Amps :10 amp
Duty cycle :30min
Max suction lift (Dry) :2.1m for Petrol, 2.5m for diesel
Max flow :20GPM (75LPM)
Motor Speed :2800rpm
Motor Speed (No-loading) :3600rpm
Discharge pressure :14psi
Min Liquid Temp :-15 °F (-26 °C)
Max Liquid Temp :150 °F (66 °C)
Meter flow rate :20-120 L/min
Meter precision :±1%

12 Volt (24 Volt ) DC rotary vane pump. Anti-explosion design.
Ideal for petrol, diesel, kerosene, mineral spirits, heptane and hexane.
ball-bearing design for the pump, unnecessary lubrication.
Cast iron material for pump body.
Thermal protection for the motor.
Bypass valve efficiently protect the motor when overload.
Filter screen in the inlet adapter.
Inlet Fitting: 1" NPT, Outlet Fitting:1" NPT
Drum Adapter Thread: 2" NPT
3/4" x 4m oil resistant rubber hose with static discharge core, 1m adjustable steel suction pipe with filter
Inleter 3/4' aluminium manual nozzle. (Optional self-closing nozzle)
Mechanical meter with aluminium die-casting body.
Easy to assemble, adjust and return to zero.
