Specifications
The vacuum metallzing machine is designed to coat the aluminum or golden or copper or others on one side of the material,such as
YZZ Model free suspension style metalizing machine
This type of machine can avoid metalize empty line,side line and wrinkle,and it adpots free floating type rolling system which is special for low tension plastic film,such as PET PE,CPP,BOPP etc,the speed can up to 600m/min.
The vacuum room is with vacuum part and rolling part,each part is with vacuum pump sets,the vacuum pump is also controlled by PLC.
The rolling system is with advanced 4 rollers and 4 motors rolling type,rolling process is controlled by SIMENS PLC,with advanced balance aluminium roller.
Main parts:
Ⅰ: vacuum
Oil pressure pump 1set
Oil diffusion vacuum pump 1 set
Roots vacuum pump 1set
Slide valve vacuum pump 1set
Super-lower temperature cold capture device 1set
Ⅱ:rolling
Wall block 2pcs
Metalizer main roller Ø500x1400
Tension roller ¢250x1400
Transction leading roller ¢120x1400
Banana roller ¢120x1400
Main roller transction 2sets
Main roller chiller 1set
Main roller’motor,rewinding motor,unwinder motor,tension motor are SIMENS AC motor.
Ⅲ:EVAPORATION SOURCE
Evaporation boat 14pcs 10x30x130mm
Positive pole sets 14pcs
Negative pole 1set
CONTROL SYSTEM
SIMENS control system,digital vacuometer ,control box, vacuum PLC control system,electric parts,touch part.
Main character:
Model No.: YZZ-2200
Vacuum working diameter: Ø2200mm
Material:PE 30-50um, PET 10-50um,PVC 20-60um,BOPP 15-60um,CPP 20-60um
Metalizer film max width: 1350mm
Material max roller: Ø800mm
Common rolling speed:500m/min
Max rolling speed:600m/min
Evaporation boats quantity: 14pcs
Evaporation boats size:10x30x130mm
Evaporation heating power:12kw
Metalizer material: Ø1.5mm aluminium wire (99.98%)
Empty chamber time:≤8min
Tension range: unwinder and rewinder 30-300N
Tension roller 0-200N
Main roller froozen system temperature: 25°C to -15°C
Metalizer thickness 0.8-6Ω
Metalizer thickness uniformity:±10%
Total power: 300kw
Voltage: 440V 60HZ 3PH
Recycle water volume: 30 m3/h
Machine weight:25T
Machine land size: 14 X 6 X3 (LXWXH)
