Specifications
1.PP LID MACHINE Special use to produce PP material2. also PS,PVC,PET cup lid,tray,plastic cover,small plastic container
PP Cover Forming Machine For Fast food Lunch Box
1. Introduction
PP-450 PP lids forming machine is a new type product developed in light of pharmaceutical standard GMP and food standard QS. This machine adopts a fully automatic flow covering blow molding or plastic suction molding, punching and diet cutting as the special properties of products required by the users. It is with advanced technology, safe and simple operation, which will avoid the consumption of labor on the manual punching and contamination from the touch with the employee. Therefore, the quality requirement is secured during the production. Aligned heating is employed by the equipment, and it enjoys low power consumption, small covering of land. It is applicable to the plastic ware such as PP , PVC, PET, PS medicine trays, and cup lids thermoforming boxes.
2. Performance features
1. Speed reducer, main-rotating connection, main shaft are on line (to decrease driving error) for mechanical transmission.
2.Sensor controls are adopted in pneumatic system .PLC control makes the whole machine run smoothly, keeps synchronous stability during the products are to be packed in multi-labor, long- distance .
3. Main motor non-stop speed regulating, the travel adjustable at will, simple and convenient to change the mold, manipulator traction, stable running.
4. Positive pressure formation in the equipment (Puffing forming)
3. Main technical parameters
Punch Frequency |
10-35punch/min |
Total Power |
9Kw |
Material thickness |
0.1-0.8mm |
Mould cooling |
Tap water or recycle water 60 L/H |
Max. Forming area |
430×240mm |
Machine dimension |
4000×1200×1700mm |
Max. Forming depth |
46mm |
Weight |
2000KG |
Stroke |
20-260mm |
Compressed air |
0.5-0.8(mpa) |
