DT300 Digital output high resolution waterproof temperature and humidity transducer
- 10000 Piece / Pieces per Month
- Beijing Tianjin
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Beijing, China | Brand Name: | Navipro | Model Number: | DT300 |
Product Description
Specifications
temperature transducer1.Temperature range: -40~120 degree
2.Humidity rnage :0~100%RH
3.Power range :12~36v
DT300 Digital output high resolution waterproof temperature and humidity transducer
Temperature measurement range | -40-120°C |
Temperature Resolution | ±0.5°C |
Humidity measurement range | 0-100%Rh |
Humidity Resolution | ±3%Rh |
Temperature measure drift | 0.01°C per year |
Humidity measure drift | 1%RH |
Power | 12~36VDC |
Signal output | 4~20mA 0~10V 0~5V RS485 |
Water-proof | IP65 |
Sampling frequency | ≤2ms |
Wallmounted temperature and humidity transmitter.Swiss SENSIRION11 temperature and humidity sensors, elegant exterior design. Good longterm stability, fullrange temperature compensation, wide temperature and humidity measurement range, high temperature and humidity measurement accuracy. With excellent longterm stability, low delay, strong ability of antichemical pollution and very excellent repeatability. HVAC applications is the accurate measurement of relative humidity and temperature of an ideal solution for the production of various kinds of high middle and low temperature and humidity transmitter according to customer requirements.
high resolution temperature sensor applications Filed
Can be applied to buildings, machine rooms, commercial, office, electronics, printing, tobacco, textiles, pharmaceuticals, rechargeable batteries and other production workshop, warehouse, granary, armory and other environmental monitoring and humidifiers, dehumidifiers control facilities.
high resolution temperature sensor working principle
Humidity sensor are generally hygroscopic substance impregnated in the insulating material, or by evaporation of the coating layer made of metal and other technology, a semiconductor, a polymer film, and the production of the powdery particles, the moisture in the moisture sensitive element and desorption process, the water molecules into H + ions out of the conducting state is changed, so that the resistance value of the element with the humidity.
temperature transducer
We provide standard,strong,protective package for our products to prevent it from outer damage. For detailed information,please refer to the pictures attached below.
We provide many kinds of economic and express shipping method for your selection.
For our temperature transducer,we provide 2 years warranty period and quick replace service.
Service standards:
- we are committed to providing a high quality,and responsive services to all clients
- The fastest reply: detailed informations, specific model and price of products will be provided quickly after receiving your inquiry.
- Quality assurance: good quality is assured by advanced manufacturing technology. And all products will be checked by our quality-control manager.
- Excellent package: each unit has individual box and all boxes are packed in standard packages.
- OEM available
We are Beijing Dingtek Technical Co.,Ltd.We especially engaged in personal gps tracker,vehicle/automotive gps tracker,liquid level sensors,industrial all in one pc.We have been in this line for many years.We provide competitive quality products and powerful customer service,and has receive high reputation from customers all over the world.
Welcome to contact us for cooperation.
If you have any questions about our product,please just contact me:)
2 years warranty period
We warrants this quality temperature transducer management to be free of defects in material and workmanship for a period of one year from the date of purchase. During the period, we will repair or replace the product at no charge for parts or labor. But the shipment fee will be shared by the buyer (one party 50%).
The time period of this warranty starts from the date of the original purchase and expires on the first anniversary date of purchase.
No express or implied warranty is made for any defects in this product which result from accident, abuse, misuse, failure to operate the product in accordance with relevant instructions, neglect, immersion in or exposure to chemicals or liquids, extremes of climate, fungus, excessive wear and tear/cosmetic damage and defects resulting from other extraneous causes such as unauthorised disassembly, repair or notification.
This warranty shall not extend to any incidental or consequential damages arising from the purchase, use or inability to use this product.
The laws of some countries and some States thereof do not allow the limitation of incidental or consequential damages, so the above limitation or exclusion may apply to you.
