We produce biomass pellet making line machines, such as wood logs debarking machine, wood logs splitter, wood sawdust making machine ,wood chipper, hammer mill, grass/straw cutter , straw bale crusher ,pellet machine and briquette machine, dryer and cooler, screener, mixer , biomass pellet boiler ,pellet packing machine and all conveyors etc.. For grinding machine for wood details as below:
1. Grinding machine for wood can crush big wood logs or timber wood branches, furniture waste, long bamboo into smaller than 5mm powder sawdust. At this moment, mostly sawdust making process is wood chipper+hammer mill two process, but now wood sawdust making machine integrates two machines advantages and can crush raw big logs into fine sawdust powder directly ,which is the most ideal equipment for biomass energy fuel plant and widely used in wood factories. Please tell us your raw wood logs diameter for us to choose best model.
2. Grinding machine for wood contains 4m length feeding belt conveyor, when conveying logs, the speed can be adjusted. Also it can connect with outlet conveyor to transport away crushed wood sawdust. The outlet conveyor can be installed at the chipper bottom or installed at the behind of chipper.
3. Grinding machine for wood has knives grinder,which can grind knives never after certain time, no need to change knives often. The full unite wood sawdust machine contains 4m length feeding conveyor ,outlet conveyor, knives grinder, electrical control cabinet etc..
4. Grinding machine for wood has limit feeding door dimension ,for example MXJ218, feed door size is700*350mm, raw wood logs diameter should be smaller than 30cm, but length no limit, feeding speed can be adjusted.
5. After crushed by Grinding machine for wood, the last sawdust powder dimension is smaller than 5mm , which can be used to press pellets directly . Wood sawdust making machine key parts are made by CNC systems, through high technical heat treatment , which are long lifetime , reasonable structure, low consumption and high working efficiency.
6. Grinding machine for wood is very hot selling more than 8000 sets per year, greatly welcome to ask me for details, we have big discount for old customer.
Model |
Capacity (t/h) |
Power (kw) |
Feeder size (cm) |
Suitable logs diameter Small than(cm) |
MXJ216-1 |
2-3 |
90/110+3+2.2 |
53*23 |
23 |
MXJ216-2 |
3-4 |
132/160+3+2.2 |
53*35 |
25 |
MXJ218-1 |
4-5 |
160+5.5+4 |
70*35 |
30 |
MXJ218-2 |
5-6 |
220+5.5+4 |
70*38 |
30 |
