Specifications
1.wood chipper used:5-8t/h2.Crush big logs into small chip:2-5cm
3.Feed door:230*500mm
4.55+3+1.5kw
5.CE,ISO9001
Drum wood chipper used application:
Drum wood chipper used is mainly used to crush raw bog wood logs or timber wood branches, furniture waste, long bamboo into small chips, the thickness of last chips is 1.5-3mm, length and width is about 2-5cm.
Drum wood chipper used characteristics :
1. Drum wood chipper used knives gap can be adjusted, then outlet chips dimension will be adjusted.
2. Drum wood chipper used contain 4m feeding belt conveyor, the conveyor speed can be adjusted when conveying logs. Also wood chipper can contact with outlet belt conveyor to transport out wood chips after crushing. The outlet belt conveyor can be installed at the wood chipper bottom or installed at the behind of wood chipper.
3. Drum wood chipper used has knives, the knives no need to change often. Generally, the knives need to grind per shift, need to change about 3-5 month.
4. Drum wood chipper used knives roller is the main part to working, which made by welded steel plate. It has good rigidity and moment of inertia. Also the knives roller is through the dynamic balance test, working stable when operation.
5. Drum wood chipper used has limit feeding door dimension, for example GX216, feed door size is 23*50cm, means raw wood logs diameter should be smaller than 23cm, but length is not limitation, feeding speed can be adjusted.
Drum wood chipper used technical parameter:
Model |
Capacity (t/h) |
Power (kw) |
Feeding size (cm) |
GX216 |
5-8 |
55+3+1.5 |
23*50 |
GX218 |
8-15 |
110+5.5+1.5 |
30*68 |
GX2113 |
15-25 |
220+7.5*2+1.5 |
35*80 |
