Specifications
1.wood pellet cooler/pellet cooling machine:1-2t/hol hot pellet:into 25C
3.1.5kw
ntain fan,cyclone,air lock
5.CE,IS
We produce biomass pellet making line machines, animal feed pellet making line machines,
fertilizer pellet making line machines such as wood logs debarker, wood logs splitter, grass cutter, straw
bale crusher, sawdust making machine ,wood chipper, fertilizer ferment upender, hammer mill,pellet
machine and briquette machine, dryer and pellet cooler, screener, mixer, pellet packing machine and
all conveyors e. c. t.
To learn our factory office and manufacture equipments , please see video as below:
For wood pellet cooler/pellet cooling machine details, as below :
1.wood pellet cooler/pellet cooling machine is mainly to cool 2-8mm diameter pellets, when outlet from pellet machines,
the hot pellets temperature is about 60-80 centigrade, after cooling, the temperature is not higher than room temperature +3-5, about 25C
2.If directly pack biomass pellet into bags after pressed by pellet machine, the pellets will be easily
broken or become moldy due to hot temperature .but after cooling , will not exist this problem. So must
cool into room temperature firstly . Especially for larger than 500kg/h capacity , must use pellet cooler.
3.wood pellet cooler/pellet cooling machine adopts counter flow theory, cold air goes inside of cooler from
bottom to top, hot pellets goes to cooler from top to bottom, as time goes on, pellets will pile up at the
cooler bottom, cold air will cool pellets from the bottom gradually,
in this way will decrease pellet broken phenomenon, if cold air also go to cooler from top, which same as
pellets flowing direction, then hot pellets will meet with cold air suddenly ,
pellets will be easily broken, especially pellets surface. In this way can cool pellets fully and equally,
pellet broken rate is smaller than 1%.
3.wood pellet cooler/pellet cooling machine generally works with cyclone and air fan, air lock.
which is used to absorb cold air and clean dust, also it can install
a screener at the cooler bottom, which can separate powder dust and good pellets after cooling.
4.wood pellet cooler/pellet cooling machine is hot selling more than 2000 sets per year , greatly welcome
to ask me for details., we have big discount at this moment.
Model |
SKLN1.2 |
SKLN1.5 |
SKLN2.5 |
SKLN4 |
SKLN6 |
SKLN8 |
SKLN10 |
|
Output(t/h) |
0.8-1.2T/h |
1-2/h |
3-5T/h |
5-8T/h |
8-12T/h |
12-15T/h |
15-20T/h |
|
Capacity (CBM) |
1.2 |
1.5 |
2.5 |
4 |
6 |
8 |
10 |
|
Cooling Time |
Not less than 10 minutes |
|||||||
Cooled Temp (°C) |
Room temperature + 3-5°C |
|||||||
Power (kw) |
0.18 |
0.25 |
0.37 |
0.37 |
0.37 |
0.37 |
0.37×2 |
|
Wind Pressure |
Higher than 200mm H2O |
|||||||
Power of Fan(kw) |
5.5kw |
7.5kw |
11kw |
18.5kw |
22kw |
30kw |
37kw |
|
