Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard

Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard thumbnail-1
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard thumbnail-2
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard thumbnail-3
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard thumbnail-4
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard photo-1
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard photo-2
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard photo-3
Hiperco27 Soft Magnetic Alloy for Sell With RoHs Standard photo-4
US$ 39.00 - 39.00 MOQ: 1 Kilogram
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Type:
Nickel Bar
Application:
Industry
Contact Supplier Request Quote Chat Now
Xi'an Gangyan Special Alloy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xi'an
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Type Nickel Bar
Application Industry
Grade Nickle
Ni (Min) 0.7
Powder Or Not Not Powder
Model Number Feco27
Brand Name xagy
Product Description



                    Hiperco27

High permeability

High saturated magnetic induction

High magnetic flux densities





Description

Hiperco27 is a new kind of soft magnetic alloy and also called FeCo27. while its permeability and the coercive force slightly smaller than hiperco50, but the mechanical toughness and ductility is better, can be competent for machining, the saturated magnetic induction intensity and Curie temperature are fairly to HiperCo50 .



Application

Aviation and aerospace components,The motor rotor, magnet pole head, relays, transducers, Magnetic shaft ,etc



Typical Chemistry(max)

C

Mn

Si

P

S

Cu

Ni

Co

V

Fe

0.025

0.33

0.30

0.015

0.015

0.75

0.75

28.5

0.35

Balance



Typical Physical properties



Electrical resistivity

7.95g/cm3

Electrical resistivity

1.9μΩ·m

Curie temperature

925℃

         Coercivity

140 A/m

residual magnetism

36x10-6

elasticity modulus

24x103 ksi(166GPa)

yield strength

1140MPa

Tensile Strength

1150MPa

elongation

7%

Saturation induction

2.40T



Typical expansion of coefficient



20 to 100℃

9.8

20 to 200℃

10.1

20 to 300℃

10.3

20 to 400℃

10.6

20 to 500℃

10.9

20 to 600℃

11.2
Packaging & Shipping

According the characteristic of material ,suitable packing and follow China Customs regulations, or  As buyer's request .

 Delivery items are flexible ,  Shipping, Air lift ,train , hight speed ground transportation ,ect



Why Us ?

1. We can tailoring your unique requirements with ASTM, UNS ,GOST, standards.

2. We can produce more people cannot produce products

3. Short Lead-time

4. Leading Edge Technology

5. Good quality control in production process, ISO9001:2008, SGS, CQC, approved.

6. Excellent quality and High cost of performance

7. Available in an extensive range of stock or custom size.

8. The whole process from raw material to finished products can be traced.

9. 40000 square meters workshop, advanced facilities and test equipment .



Our Services

1.Sample free

2, Faster delivery
3, Helpful staff
4, Quick response
6, Testing before shipping
7, We will reply you for your inquiry in 24 hours.

8, Advanced facilities

9. Technical support

10. No min order request

11.Technical Information
If you have a technical question relating to a Controlled Expansion, Electrical/Electronic Nickel, Soft Magnetic or Refractory application, or need assistance with a specific material, you can visit our web  or email supportsales©  Ask the Experts service .

FAQ



1.Q: How can I trust this factory ?

   A: Our stock number is 836660(China new stock market), also you can visit our website . Our factory's License and certificate appear on the website.(License Number can check the aptitude of the factory on Chinese Gov web ,English version available )

2. Q: Is this factory far away from the port? Is this will take longer for delivery?

   A: From Xi'an to any port in China with in one day, convenient transportation only can improve the delivery.

 3. Q: Where is your factory located? How can I visit there?

   A: Our factory is located in Xi'an, Shaanxi Province, China.
       All our clients from all over the world, are warmly welcome to visit us! Free pick up !

4. Q: How can I get some samples?
     A: We are honored to offer you samples.(sample will delivery as our stock size)
5.Q: How does your factory do regarding quality control?
   A. Quality is priority. our factory have advanced facilities, High qualified technical personnel and technical support and always attach great importance to quality controlling from beginning to end. All requirements with ASTM, UNS, GOST standards.

6.Q Are you ISO 9001 approved ?

  A:Yes,we have held ISO 9001 approval since 2000.

7.Q;How can I pay ?

  A: Payment can be made by T/T, L/C, D/A, D/T ,Western Union .

8.What is your minimum order quantity?

A: We can manufactures from as small as few kilogram to your specification.

9.Q:What is your standard of the lead time ?

  A: Typical manufacturing lead times are around three working weeks.

     If you have an urgent requirement, we have an emergency manufacturing service(EMS)available .

10.Q:Do you offer testing services?

   A:Yes ,we can offer test date for you. Although we are not certified by international authority, our equipment is regularly calibrated and certified and our staff are fully competent. We can carry out for you ,using our in-house equipment.

11.Q:Do you deliver worldwide ?

   A: Precision alloy supplies customers world wide.by Air, Sea, Ground, We can despatch using your  carrier account if you prefer.  All products are packed suitably for transportation.

12.Q:Can you make to my specification/drawing ?

A:We do manufacture to individual specifications / drawings.  Please send us your specification / drawing for our production team to confirm if we can meet your requirements.

13.Q: Who do I send my enquiry to?

   A: Please send your enquiries to Supportsales⊕

14.Q: Who do I contact when progressing my order?

   A: Send an e-mail titled Order Progress to Supportsales⊕



Xi'an GangYan Special Alloy Co,Ltd  The  factory is  researching and producing  precision alloy over 23 years , Worldwide Supply and 10000+ clients witness for you .
      Our factory is located in Shaaxi Province of China. Our products are all made to satisfy the requirements of the European Union SGS ---RoHs,  ISO 90001 and we have both certification. Our advantage lies in strong research-and-development capabilities, abundant materials, highly cost performance, and relevant relations with the factories from all over the world .The table showing is reference Only ,Other shape available as well , also we can tailoring your unique requirements with ASTM, UNS ,GOST,standards,   For any Further INFO please feel free to contact us: supportsales⊕
