Specifications
1.chicken feed mixing machine:500kg/batch2.11kw
3.mix animal feed soybean,maize,grain powder
4.double paddle shaft
5.CE,ISO
Chicken feed mixing machine application:
Chicken feed mixing machine can mix maize, corn, soybean, wheat, grain and other feed material powder for animal or poultry use.
Chicken feed mixing machine working principle:
The chicken feed mixing machine consists of two opposite direction of rotation of the rotor.There are several special angles welded blades.On one hand, the blade lead material counterclockwise rotation along the slot inner wall surface, on the other hand, driven material turning left or right. Then forming a floating zone at the overlap part of two rotor. In this region, no matter the material shape, dimension and density, all material will float, lost in an instant heavy state, thereby enable the raw material in continuous turning in the slot part, thus achieve the even and high efficiency mixing effect.
Chicken feed mixing machine characteristics :
1. Chicken feed mixing machine mainly used for feed and fertilizer industry.
2. Chicken feed mixing machine has full length discharging door, discharge speed is fast, no residual of raw material. Input door generally has two, more convenient to add raw material. Input and output door both have manual and pneumatic type, generally larger than 1000 model will use pneumatic type, thus no need manual.
3. Chicken feed mixing machine mixing time is very short, will use 40-90 seconds/batch.Adding input and output time, mixing time is 10-15 minutes per batch(full load working), thus it can mix 4-6 times per hour. Homogeneity degree is very high(CV is smaller than 5%).
4. Chicken feed mixing machine has double paddle shafts, mixing efficiency and working balance are both high. The feed mixer has carbon steel and stainless steel two kinds, can choose by your requirement.
5. Chicken feed mixing machine rotor got dynamic balance test, will working stable when operation. The gap between shaft and tank body design is very reasonable, mixing efficiency, no dead angle.
6. Chicken feed mixing machine can add liquid, mixing evenly even contain 30% liquid. Also can mix viscous material.
7. Chicken feed mixing machine chain sprocket adopts three rows chain structure, the rotor will rotate at the drive of cycloid reducer with same direction. The transmission mechanism is unique, working very stable when operation, transmission torque is big, low wear and tear.
Chicken feed mixing machine technical parameter:
Model |
SSHJ- 100 |
SSHJ- 250 |
SSHJ- 500 |
SSHJ- 1000 |
SSHJ- 2000 |
SSHJ- 3000 |
SSHJ- 5000 |
Output (kg/batch) |
100 |
250 |
500 |
1000 |
2000 |
3000 |
5000 |
Power(kw) |
3 |
5.5 |
11 |
22 |
30 |
37 |
45 |
Actual volume(CBM) |
0.2 |
0.5 |
1 |
2 |
4 |
6 |
10 |
|
Homogeneity degree (CV) |
<5% |
||||||
|
Mixing period of the machine (s) |
40-90 |
||||||
Inner shaft |
Double paddle shaft |
||||||
