Metal Gate Digital Lock Wiegand 26 Controller Standalone RFID Reader HSY-S209

Product Parameters:

Model No:

HSY-S209 (waterproof)

Low power consumption:

less than 30mA standby current

Luminous keyboard:

the night can also operate keyboard

User capacity:

support 2,000 users

Independent password:

can use password which irrelevant with the card to open the door

User modification password:

Users can revise the door password

Search speed:

charge to open the door time less than 0.1 S.

Output short circuit protection:

electric lock or alarm output circuit within 100 μS when shut down automatically output

Wiegand output:

With Wiegand output interface,Wg26 card number or Wg4 buttons output

Usable keyboard delete card number:

After card is lost, usable keyboard delete card, Thoroughly eliminate safety lapses

The demolition alarm:

Illegal dismantling machine, built-in alarm sound buzzer

The bell button and interface:

key and circuit segregation, external any the doorbell.

Technical parameters:

Working frequency

125khz or 13.56mhz

Standard interface

Wiegand 26 input

Work Voltage:

DC9-28V

Static Current:

≤30mA

Reading Range:

3~8cm

Waterproof degree:

IP68 rating

Ambient Temperature:

-25~60 Degree

Ambient Humidity:

10%~90%

Electricity lock output:

≤3A

Alarm output:

≤20A

Output short circuit protection time:

≤100μS

Open time:

0 ~ 99 seconds (adjustable)

Size:

120(L) x 80(W) x 25(H) mm
