Home > Security & Protection > Access Control System > Access Control Card Reader > 125khz LF RFID Reader Manufacturer

125khz LF RFID Reader Manufacturer

US$ 1 - 17.49 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

HSY

Model Number:

HSY-R131

Contact Supplier Request Quote Chat Now

Shenzhen HSY Security Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name HSY

Model Number HSY-R131

HSY-R131 125khz LF RFID Reader manufacturer

Advantage:

1.16 years experience professional in RFID products

2. OEM/ODM orders are welcome;

3. Professional techniques supports;

4. Best quality,Best price,Best Service.

Product Description

Introduction:

RFID card reader is a standard Wiegand26 bit output format and an off-contact high performance reader. Its main use is as a supplementary reading device for the controller which has the wiegand interface. It characters with exquisite appearance, convenient installation and stable characteristics.

125khz LF RFID Reader Specification:

Model	HSY-R131
Output Interface	Standard WG26 or WG34,Optional RS485/RS232
Operating Frequency	125KHz
Reader Card	EM Card, IC Card
Transmitting Distance	WG<100M
Proximity Range	3-15cm
Power Supply	DC9~12V
Static Power Supply	50~70mA
Temperature	-20°C~60°C
Relative Humidity	10%-90%
Recognition Speed	<=5s
LED	Built-in LED (Double Color LED)
Buzzer	Built-in Loud Speaker
Color	Dark grey
Material	ABS Case Material (Black Resin for Water-Proof Function)
Waterproof	IP65 Degree
Dimension	117.352.729 (mm)
Package	100pcs per carton. Carton Size: 43.55623(cm)

125khz LF RFID Reader Sample shows:

Installation:

Using “+”type screw driver to loosen the screw between the panel and motherboard. And then embed the motherboard to the side wall with the plastic plug and screws.

Notice!!!

1. Confirm the electric voltage (DC12V) and differentiate positive anode and cathode of power supply

2. When external Power is used, make sure sharing the power with Controller Box or using the same GND

3. The wire connects reader to controller, advise use 8 cores stranded twisted pair cable(among them, three strands are spare, if no need reader show illegal card s by sound and light, LED wire can not be used, data wire Data1 Data0 are twisted pair would be better, we suggest sectional area are 0.22 square millimeter at least. The length should not exceed 100meters.

Packaging & Shipping

Shipping :

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door service;

2. By Air or by Sea for bulk goods, for FCL; Airport/ Port receiving;

3. Support Customers specifying freight forwarders or selected shipping methods!

4. Delivery Time: 2~7 working days. Accurate deliver based on your quantity .
