Help CenterPromotion! C321 Frequency Adjustable Backpack SDI Transmitter
Related Products
-
Backpack Wireless HDSDI Digital COFDM ModulatorUS$ 1 - 10,000MOQ: 1 Piece -
15-20km C331 Long Range NLOS Digital Transmitter for Mobile VehicleUS$ 1 - 10,000MOQ: 1 Piece
-
H.264 HD 1080P COFDM Vehicle-bone HDMI Wireless ReceiverUS$ 1 - 4,000MOQ: 1 Piece
-
TDD Small Portable Base Station Best RangeUS$ 1 - 1,500MOQ: 1 Piece
-
Radio Broadcasting Equipment With Monitor Mini COFDM Transmitter and ReceiverUS$ 1 - 10,000MOQ: 1 Piece
Product description:
C321 SDI COFDM wireless video portable Transmitter,popular products and complete function,easy to use,small size.Using COFDM modulation technology and MPEG-2 image compression technology.set the transmitting antenna,power amplificaion,digital modulation,audio and video digital compression in one. It can transmit real-time stability HD-SDI audio and video in fast-moving and buliding sheltered environment.The product is widely use in security, fire protection,emergency communication and other important department.
Features:
1. Using COFDM modulation technology and MPEG-2 image compression technology
2. Have the strong ability of NLOS transmission, move ability,penetrating power,diffraction ability and anti-fading.
3. 8M channel bandwidth,ensure the audio and video high resolution,the operating frequency can be set within the specified range
4. Support DVD image format,No mosaic, save the last good frame
5. Mainly to solve the short distance and in the long range of NLOS,urban,underground garage,inside and outside building digital video wireless mobile real-time transmission.
6. Compact equipment structure, small size, good scalability
7. Aluminum alloy design, dustproof,moistureproof,anti vibration,anti impact
Produt application:
The product is widely use in security,fire protection,emergency communication and other important department.
C321 Transmitter technology parameters
Model |
C321 |
| Voltage | DC12V |
| Current | 1800mA |
| Video input | BNC port,external SDI analog video signal |
| Bandwidth | 2/2.5/4/8MHz |
| Radio Frequency | The optional 300MHz~900MHz, Stepping 1MHz (It can be customizes for other frequencies) |
| Output power | 20dBm~30dBm,stepping 1dBm adjustable |
| Decryption | AES |
| Modulation model | COFDM,2K |
| Transmission rate | 1.5Mbps-6Mbps |
| FEC | 1/2,2/3,3/4,7/8 |
| Guard Interval | 1/32,1/16,1/8,1/4 |
| Video processing method | MPEG-2 |
| Parameter adjustment | Through the control panel to set the relevant parameters |
| Antenna port | N(50Ω) |
| Audio input port | Lotus |
| Operating temperature | -10°C~70°C |
| Dimensions | 158mm*100mm*52mm |
