1/3" CMOS ir waterproof wireless ip camera

Image Sensor

1 / 3" 2.0 megapixel progressive CMOS sensor,

Minimum illumination

0.1 Lux

Video Standard

CMOS

Scanning systems

Progressive

Processor

Hi3512

Lens

Optional 6mm/8mm/12mm fixed aperture lens
(6mm with the best effect between5-10 m, 8mm with the best effect between10-20 m, 12mm with the best effect between20-30mm ,16mm with the best effect between 30-50m

Video Compression

H.264 Main Profile @Level 3.0 / MJPEG

Dual Streaming

Support

Resolutions

Primary Stream:1600*1200(15fps), 1280*960 (22.5fps), 1280*720 (30fps) Secondary Stream: 800*600, 400*288, 192*144

Video Frame Rate

1~25fps(other definitions) Secondary Stream:1~25fps

Video Bitrates

32Kbit/S-16Mbit/S

Audio Compression

G.726

Talkback Input

1 channel MIC output

Audio Output

1 channel Linear output

Alarm Input

1 channel on/off output, 120VAC 1A/24VDC 1A

Title OSD

Supports channel name, date, and video stream information overlay; OSD location is adjustable

SD Card Interface

Support video storage and image snapping; SD2.0 standard, maximum storage 32G

Control Interface

1 RS485 interface

Alarm Output

1 channel on/off output, 120VAC 1A/24VDC 1A

E-mail Based Alert

Support

RTSP Protocols

Support, you can view live video by VLC player

FTP Protocols

Support, auto upload images to a ftp server.

Mobile Monitor

Supports smart mobile phones that are based on Windows Mobile 6, Symbian v3, v5 and iPhone.

Wireless

Support 802.11b/g protocol, frequency 2.4GHZ, the wireless distance can be 100 meters without block

Wireless Encryption Protocol

Supports WEP,WPA,WPA2

Waterproof level

Comply with IP66 standard

Power Input

DDC12V/3.0A

Power Consumption

<12W

Size

248mm * 110mm * 110mm
