600TVL Sony Super HAD II CCD Camera

600TVL Sony Super HAD II CCD Camera thumbnail-1
600TVL Sony Super HAD II CCD Camera photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Bellsent
Model Number:
BE-CL80HB/DI
Contact Supplier Request Quote Chat Now
Shenzhen Bellsent Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Bellsent
Model Number BE-CL80HB/DI
Type Other, CCD Camera
Style Bullet Camera
Sensor CCD
Technology Other, advanced ISP with 14bit convertor
Special Features Other, Low illumination

Specifications

The newest SONY CCD and advanced ISP
True Day&Night, 3D DNR function
OSD menu remote control from RS485
flexible application

Features

This model adopts the newest SONY CCD and advanced ISP with 14bit convertor, it is a high definition, full function and super-low illumination camera, it is designed as per the newest 600TVL solution, with built-in 3D DNR function, it can effectively reduce the noise on image displayed under super low illumination at night, and the OSD Menu inside can be remotely controlled through RS485, which makes the camera more convenient to use. Completed functions make its performance perfect for every installation!

This model can be widely used in traffic, building, airport, hospital and so on.



Features

* The newest SONY CCD and advanced ISP

* High resolution 600TV Lines super low illumination

* OSD Menu,Remote control through RS485

* True Day&Night, 3D digital color reduction

* X256 times SENSEUP Function can effectively improve the low illumination effect.

* Motion Detect Output and Privacy Zone Masking Function.

* Shutter speed adjustable for the convenience of application.

* Built-in IR-CUT Module (Excellent colour reproduction at daytime

        Enormous light volume at nighttime yields perfect night vision)

* Mirror/ Flip/ Rotate Function

* Digital Pan/ Tilt/ zoom (x2)

* Dynamic Range Control/ Eclipse

* Dual power design



Specification

Model

                                     BE-CL80HB/DI

Video System

PAL/NTSC

Sensor

Sony Super HAD II CCD

Pixel

PAL:(H)795x(V)596; NTSC:(H)811x(V)508

Control mode

OSD/Remote RS485

IR cut

Yes

Privacy mask zone

4 zone

S/N Ratio

52dB(min)/60dB(standard)(AGC OFF)

Illumination

0.01Lux / F1.2 (day/night IR mode)

0.00035Lux/F1.2 (Sense Up Mode)

Sync. Mode

Int/L.L

Gamma correction

0.45

AGC

+26dB (Max)

Lens

                                 Manual iris/Auto iris

Electronic Shutter

1/50~1/100,000s(PAL),1/60~1/100,000s(NTSC)

Power Supply

DC12V/AC24V±10%, 350mA at DC12V(Max)

Work environment

-10 ~+50°C RH95%MAX

Dimension

115x70x62(mm)

Weight

500g
