Home > Lights & Lighting > LED Encapsulation Series > LED Module > 1.2W 64LM RGB LED Module,4pcs PVC 2700K SMD LED Module,RGB SMD Module
1.2W 64LM RGB LED Module,4pcs PVC 2700K SMD LED Module,RGB SMD Module
US$ 0.6 - 3
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Model Number:
BW-MD1002
Chip Material:
Other, PVC, ABS PLASTIC
Emitting Color:
Warm White
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5730 LED Module,3 Chips 5730 LED SMD Module,CE&RoHS 5730 SMD Module LEDUS$ 0.2 - 3MOQ: 100 Pieces -
High Power LED Module,2 Chips Small LED Module Light,NEW LED Light Product for 2013US$ 0.2 - 3MOQ: 100 Pieces
-
White Housing LED Driver Module,SMD5730 LED Driver Module,3 Chips 1.2W SMD LED ModuleUS$ 0.2 - 3MOQ: 100 Pieces
-
High CRI Injection LED Module,LED Emergency Lighting Module,Waterproof 5730 LED ModuleUS$ 0.2 - 3MOQ: 100 Pieces
-
Square Shape 5050SMD LED Modules BacklightsUS$ 0.6 - 4MOQ: 100 Pieces
Model Number
BW-MD1002
Chip Material
Other, PVC, ABS PLASTIC
Emitting Color
Warm White
Luminous Intensity
67
Luminous Flux(lm)
48
Optical Attenuation(%)
1
Power
Other, 1.2
Power Dissipation
0.4
Color Rendering Index(Ra)
80
Color Temperature
2700K,4500K,6000K
Operating Temperature(℃)
-20, 50
Storage Temperature(℃)
-20, 60
Place of Origin
Guangdong, China
Brand Name
Brightway LED Limited
Certification
CE
Specifications
RGB LED Module1.Led module IP65
2.12V High Brightness LED module
3.Channel letter sign LED back light
4.2/3/4LED CE&RoHS
1.2W 64LM RGB LED Module,4pcs PVC 2700K SMD LED Module,RGB SMD Module
LED Module Introduction:
1,Injection Module adopts ABS material as its shell. transparent epoxy resin around the lights with good insulativity.
2,Comprehensive performance , good with excellent electrical performance, impact strength and wear resistance, chemical resistance, moisturecontent , shaping and excellent machining technology.
3,Completed through injection in one time. solves the problem that nonuniform sealing, dirty shell and LED stand out of the glue etc. It is simple artwork with good appearance and short lead time as well.
4,Good cold resistant available for -20~40°C. 3M adhesive tape and screws for customers to fix it in easy installation.
LED Module Details:
| Part No. | Color | LED chip | LED Qty (pcs) | Input Volt | Power (watt) | Lumens | Viewing angle | IP Rank |
| BW-MD1001 | Pure white Warm white Red Green Blue Yellow | SMD3528 | 3 | DC 12 | 0.3 | 24LM | 140° | IP65 |
| BW-MD1002 | SMD5050 | 3 | 0.72 | 48LM | ||||
| BW-MD1003 | SMD5050 | 4 | 1.2 | 64LM | ||||
| BW-MD5001 | Pure white Neutral white Warm white | SMD5730 | 3 | 1.2 | 110LM | |||
| BW-MD5002 | SMD5730 | 2 | 1.2 | 85LM | ||||
| BW-MD5003 | SMD5730 | 3 | 1.2 | 110LM | ||||
| BW-MD6001 | CREE XP-E | 1 | 1.3 | 95LM |
LED Module Features:
1. Unique design, ABS PLASTIC Molding shell, adopting high brightness S,3528 SMD5050 SMD5730.
2. High llighting efficiency which can reach 90lm/W.
3. IP Rand: IP65.
4. Adopting with DC12V constant voltage driver.
5. With retrofitted holes and 3M tape, two installation choice.
LED Module certification:
LED Module Applications:
