tissue paper cutting machine
tissue paper cutting machine description
Automatic monolithic packing wet paper machine is a can the whole roll of base paper by unwinding, longitudinal folds, and liquid and fixed length cutting, and then the lateral fold, then after packaging film package and sealing positioning and cutting machine. The whole production process is operated by the machine, without manual contact, to ensure the health of the product.
tissue paper cutting machine main technical parameter
Paper: spun lace non-woven cloth, hot rolled
The paper specification: Max W220mm, 1400mm
Max W1050mm, 1000mm
Axis number setting: 80 axis Paper (automatic connection type 32 axis)
Ventilation shaft diameter: 3"
Applicable package material: BOPP PET/AL/PE PET/PE and other heat sealing material
Film specifications: Max W420mm, 350mm
Axis number setting: 2 - axis roll film, no stop automatic transfer
Ventilation shaft diameter: 3"
Application: transparent and non transparent
Label size: Max W100mm, 400mm
Axis number setting: 2 axis label affixed, automatic conversion (can be set to the safe).
Ventilation shaft diameter: 3"
Folding style: independent and continuous extraction
Wipes size: L120-250mm W90-115mm
Expanded size: W150-220mm L120-250mm
Package size: L150-350mm, W80-120mm, H20-100mm
Design speed: 120 packs of /min& 250 knife /min, up to the first
Production speed: 100 /min& 200 knife /min, the first
Floor area: W3500mm H2100mm L54000mm
W4600mm H2100mm L57000mm (automatic barge model)
Power requirements: 50/60Hz 35KW AC380V (automatic barge model 40kW)
Air source requirements: 500L/min 0.6-0.8Mpa
Machine net weight: about 30000kg (automatic barge type 35000kg)
Optional configuration: date marking machine mother volume automatic transfer
tissue paper cutting machine characteristics
1.Control system: multi axis motion controller
2.Drive unit: servo motor
3.Operating interface: 10 "LCD touch screen
4.Cut off: synchronous flail wipes
5.Packing: automatic diversion, 2 packaging machine packaging, can be online
6.Paperback mechanism: 80 groups of paper back belt (automatic transfer model 32 group)
7.Frequency detection: 80 eye detection
8.Traction frequency: 4 groups of 2 groups, the accumulation of dry towel wipes accumulated traction
9.Automatic transfer: automatic transfer of film and film, automatic conversion
10.Frequency dividing detection: distribution, film, and standard interface detection
Metal detection: Online metal detection
11.The bad: eliminating aluminum interfaces eliminate Online
12.Flow control: 2.5-4 times flow meter measure and control, no residual liquid recovery
13.Injection method: 80 liquid pipe independent spray
14.Stirred tank: 2 1000L stainless steel mixing tank
15.Liquid level control: automatic control of electronic detection
tissue paper cutting machine picture
tissue paper cutting machine sample
