Home > Products > Thermosetting Plastics > Leton epoxy fiber glass laminated sheet
Leton epoxy fiber glass laminated sheet
- 100 Ton / Tons per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Leton | |
| Model Number | Leton FR4 | Material | Other, fiber glass cloth | |
| Thickness | 3mm-100mm, 3-100mm | Size | 1020mm*2020mm, 1020x2020mm |
Product Description
Leton Epoxy Fiberglass Cloth Laminated Sheet
Name: G10 Epoxy Sheet
Material: Fiber Glass Cloth
Temperature Resistance: 180 centidegree
Inflaming Retarding: No
Arc Resistant: No
Feature: Excellent mechanical strength, stable size, chemical resistance and moisture resistance
Application: Generator ,transformer, fixture, inverter, motor and electric insulation component
Partial Epoxy Sheet Data Sheet
| Standard Application | JIS | _ | EL-GEM | EL-GEF | EL-GEH |
| |
NEMA | _3240 | G-10 | FR-4 | G-11 | FR-5 | |||
Material | Epoxy Resin | Epoxy Resin | Epoxy Resin | Epoxy Resin | Epoxy Resin | |||
Test Item | Unit | Treatment conditions | Fiber Glass cloth | Fiber Glass cloth | Fiber Glass cloth | Fiber Glass cloth | Fiber Glass cloth | |
Parallel Layer Direction Voltage Withstand on 1 minute | kv/mm | C-90/20/65 | 13 | 15 | 15 | 15 | 15 | |
Vertical Layer Direction Voltage Withstand on 1 minute | kv | O-0.5/90 | 13 | 15 | 15 | 15 | 15 | |
Insulation Resistance | Normality | MΩ | C-90/20/65 | - | 106×108 | 106×108 | 106×108 | 106×108 |
After boiling | MΩ | C-90/20/65 +D-2/100 |
| 104×106 | 104×106 | 104×106 | 104×106 | |
Notes: treatment condition (The testing type of the experimental samples):
A. Receiving state
C. The treatment of constant temperature and humidity
D. The treatment in the Constant temperature water soaking
E. The treatment in the constant temperature air.
F. The treatment I in the constant temperature oil
---- The initial value of processing time in the previous handling,
----The first numerical treatment temperature
----- the first relative humidity of the numerical treatment
