ELM327 with WIFI &WI-FI OBD2 AUTO CHECKER Diagnositc interface

Specifications

Specifications
1.One year warranty
2.Easy to operate
3.The best quality and wholesale price
4.The best service

      ELM327 with WIFI &WI-FI OBD2 AUTO CHECKER Diagnositc interface

ELM327 with WIFI WI-FI OBD AUTO CHECKER



Product Description

wifi 327 can be used on Iphone,Ipad and so on...

Wifi OBD VGATE Technical Specifications IP: 192.168.0.10 Subnet: 255.255.255.0 Port: 35000 Range: 50 ft (Line of sight) Antenna: Internal Power Consumption: 0.75 Watts (With Power Switch) Wifi Standard: 802.11a/b/g Operating Temperature: -15 to 100 Deg Celsius Plastic: Automotive Grade Physical Dimensions: 2.75 x 1.25 x 1.2 inches

Description WI-FI OBD AUTO CHECKER is capable of communicating with vehicles which adopt following protocols: ISO 9141 ISO 11898(aka. CAN) ISO 14230(aka. KWP2000) ISO 15765(aka. CAN) SAE J1939





WI-FI OBD AUTO CHECKER is capable of communicating with vehicles which adopt following protocols:



WI-FI OBD AUTO CHECKER is able to detect and interpret these protocols automatically. It also provides support for high speed communications and a low power sleep mode. It use AT commands to communicate with a host device (PC, notebook, iPhone, iPod touch, iPad and so on). There are plenty of software packages available, which are fully compatible withWI-FI OBD AUTO CHECKER. Some of them have pretty useful features, such as engine running parameters monitoring, DTC reading and clearing, MPG meter, etc. You can even write your own software on a specified hardware platform if you wish, because the AT commands are fully documented and very well explained.WI-FI OBD AUTO CHECKERis measuring only 2.7 x 1.25x 0.9 inches, and it comes attached with a 6 ft OBDII cable for easy installation. It also comes included with a power switch built-in to prevent the need for having to constantly disconnect your unit from the OBDII port.It is compatible with 1996 and later vehicles. Connecting to your iPhone / iPod touch /iPad is made by WIFI connection in adHoc mode.

Elder OBD compatible vehicles has a sticker indicates that the vehicle is OBD compatible.Model year 1996 and newer vehicles are compliant by default, and will not have this sticker.

Following are some of the parameters which could be read from the vehicle.

Vehicle Speed

RPM

Fuel Consumption*

Engine Coolant Temp

Fuel Pressure

Calculated Engine Load

Throttle Position

Intake Manifold Pressure

Air Intake Temp

Timing Advance

Mass Air Flow

Fuel Level

Barometric Pressure

EVAP System Vapor Pressure

Fuel Trim

*note: Your vehicle may not support all above parameters. How many parameters you can get is depended on the vehicle manufacturer’s implementation.

Vehicles supported

Our device works on all 1996 to 2010 cars and light trucks sold in the United States, including:

Acura Alfa Romeo Ariel Atom Aston Martin For Audi Bentley For BMW Buick Cadillac Chevrolet Chrysler Citroen Daewoo Daihatsu Daimler Dodge Ferrari Fiat Ford Geo GMC Holden For Honda Hummer Hyundai Infiniti Isuzu Jaguar Jeep Kia Lamborghini Lancia LandRover Lexus Lincoln Lotus Maserati Mazda McLaren Mercedes Mercury MG Mini Mitsubishi Nissan Oldsmobile Opel Pagani Panoz Peugeot Plymouth Pontiac For Porsche Regal Renault Rolls-Royce Roush Rover Saab Saleen Saturn Seat Scion S...helby Skoda Smart Subaru Suzuki Tesla Toyota Triumph TVR Vauxhall Volkswagen Volvo Yugo...
